Indoor P1.86 Small Pixel Pitch LED Display for TV Station and Studio Room Usage Indoor HD LED Screen Panel Video Wall Display

Product Description

Description:
Indoor P1.86 Small Pixel Pitch LED Display for TV Station and Studio Room Usage Indoor HD LED Screen Panel Video Wall Display
https://seekstarled.en.made-in-china.com/product/CZNtTHjxMXhB/China-High-Gray-Scale-Indoor-Full-Color-LED-Display-Screen-P2-5-P3-P4-P5-P6-P10-for-Stage-and-Meeting.html
LED is the abbreviation for light emitting diode. LEDs are arranged in vertically and horizontally with a stable pitch that forms LED matrix LED Display Screen. Each of the LED Display has a corresponding brightness control circuit. The computer controls the circuit, which affects the brightness of each LED and then forms the image we want in the LED display.
LED display screens are widely used in government agencies for government affairs, stations, banks, taxation, post and telecommunications, hospitals, customs, securities markets, bidding markets, schools, factories, ports, stadiums, airports, industry and commerce, taxation, customs, monitoring centers and advertising. The entertainment industry, and real estate trading centers and other window industries that need publicity, as well as highways, urban traffic management, urban environmental index display, etc.
Specification:

Indoor Small Pitch Full Color LED Display
Product Item	Indoor P1.25	Indoor P1.538	Indoor P1.667	Indoor P1.86	Indoor P2
Pixel Pitch	1.25mm	1.538mm	1.667mm	1.86mm	2mm
LED Type LED	RGB 3in1	RGB 3in1	RGB 3in1	RGB 3in1	RGB 3in1
LED Life LED	100,000 hours	100,000 hours	100,000 hours	100,000 hours	100,000 hours
Configuration	SMD1010	SMD1010	SMD1010	SMD 1515	SMD1515
Module Size	320x160	320x160	320x160	320x160	320x160
Module Resolution	256*128	208*104	191*96	172*86	160*80
Pixels Density (dots)	640000	428000	360000	288906	250000
Brightness (cd/sqm)	0-1400 adjustable	0-1400 adjustable	0-1400 adjustable	0-1400 adjustable	0-1400 adjustable
Viewing Distance	≥3m	≥3m	≥3m	≥3m	≥3m
Viewing Angle	160°/160°	160°/160°	160°/160°	160°/160°	160°/160°
Refresh Rate	1920-3840HZ	1920-3840HZ	1920-3840HZ	1920-3840HZ	1920-3840HZ
Gray Scale	16bit. Red, Green and Blue each 16K	16bit. Red, Green and Blue each 16K	16bit. Red, Green and Blue each 16K	16bit. Red, Green and Blue each 16K	16bit. Red, Green and Blue each 16K
Color Temperature	3000K-9500K adjustable	3000K-9500K adjustable	3000K-9500K adjustable	3000K-9500K adjustable	3000K-9500K adjustable
Scan Mode	1/64scan	1/52scan	1/48scan	1/43scan	1/40scan
Cabinet Material	die-casting aluminum	die-casting aluminum	die-casting aluminum	die-casting aluminum	die-casting aluminum
Cabinet Size (mm)	640x480	640x480	640x480	640x480	640x480
Cabinet Weight(kg)	11kg	11kg	11kg	11kg	11kg
Max Consumption (W/sqm)	800	800	800	800	800
Ave Consumption (W/sqm)	270	270	270	270	270
Supply Voltage	AC220V/50HZ; AC110V/60HZ	AC220V/50HZ; AC110V/60HZ	AC220V/50HZ; AC110V/60HZ	AC220V/50HZ; AC110V/60HZ	AC220V/50HZ; AC110V/60HZ
Storage Temperature	-30ºC~+80ºC	-30ºC~+80ºC	-30ºC~+80ºC	-30ºC~+80ºC	-30ºC~+80ºC
Working Temperature	-20ºC~+60ºC	-20ºC~+60ºC	-20ºC~+60ºC	-20ºC~+60ºC	-20ºC~+60ºC
Operating Humidity	10%-80%	10%-80%	10%-80%	10%-80%	10%-80%
IP Rating	IP20	IP20	IP20	IP20	IP20
Display Capacity	Text, Graph and Video	Text, Graph and Video	Text, Graph and Video	Text, Graph and Video	Text, Graph and Video
Control System	LINSN,Nova-star Colorlight (adjustable)	LINSN,Nova-star Colorlight (adjustable)	LINSN,Nova-star Colorlight (adjustable)	LINSN,Nova-star Colorlight (adjustable)	LINSN,Nova-star Colorlight (adjustable)
Control Mode	Synchronous Control Mode	Synchronous Control Mode	Synchronous Control Mode	Synchronous Control Mode	Synchronous Control Mode

Features:
The perfect design of the light board PCB and the hign-end selection of IC can easily achieve high grayscale, high refresh and high brightness.
High grayscale: Brightness can be adjusted according to the environment, the details are clearer.
High refresh: High refresh rate, the screen playback is clearer and smoother.
The color is richer and more delicate,in the case of high brightness, the color is not distorted and the picture quality is clear.
Installation:
No need to change any building structure for installation.
Fast maintenance design.
Wide viewing angle
Application:
Advertising publish / retail store / shopping mall / display of dishes / welcome display / self-service business / exhibition hall / airport / subway / elevator / restaurant & hotel supplies / education / medical treatment /
Indoor magnesium alloy full color screen: The cabinet is made of magnesium alloy. Light weight, thin thickness, beautiful appearance
