sales promotion Cassava manioc yuca peeling and chipper machine

Product Description

Product Description
1.. company introduction : cassava peeling and chipper machine
Henan Jingxin Machinery CO.,LTD is a machine manufacture, established in 1990,with 120 employees
2. details for the machine
This machine has the two functions ---peeling and chipping . the machine is easy to be operated , and with high capacity ,the capacity can be 10 tons per hour.
How to adjust the slicer thickness?
First step:we can loose the screws which are mainly used to tighten cutter plate and blade to change the distance (1.5-2.0cm is the best)between cutter plate and blade.After adjusting the distance into our requirement,we should tight the screws again.
Second step:loose the screws which tight the feeding funnel in order to adjust the distance (2cm is the best)between feeding funnel and the cutter blade .After making sure there is no friction between the feeding funnel and blade plate,we can tight the screw again.
3. details parameters :

Items	JX-4	JX-10
Capacity	4t/h	10t/h
Peeling rate	>85%	>85%
Cutting size :	5-15mm	5-15mm
Machine size	3.5*1.5*0.8mm	3.0*1.2*0.8m
Motor	1.5kw*2	1.5kw
Weight	500kg	230kg
