Vertical and Horizontal Universal Milling Machine (X6330W)
| US$1.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
X6330W
Structure
Horizontal and Vertical
Milling Cutter Type
Other
Milling Cutter Structure
Other
Controlling Mode
Artificial
Automatic Grade
Automatic
Precision
High Precision
Certification
GS, CE, ISO 9001
Condition
New
Table Size
1370X305mm
Spindle Taper
R8(V);Nt80(H)
Spindle Speed
66-4540(V);40-1300(H)
Travel Longitudinal (X)
800mm
Trave Cross (Y)
380mm
Trave Vertical (Z)
360mm
Distance Spindle to Column
155-635mm
Arm Travel
500mm
Table Load
350kgs
Net Weight
1550kgs
Transport Package
Wooden Case, No Need Fumigation, Plastic Cover
Specification
CE, ISO9001
Trademark
UNI-TECH
Origin
Shandong, China
HS Code
84592900
Production Capacity
400PCS/Month
Product Description
Vertical and Horizontal universal milling machine (X6330W) Specification of our universal milling machine:| Specification | Unit | X6325W | X6330W |
| Table size | mm | 1270X254 | 1370x305 |
| T slot | 3/16/65 | 3/16/65 | |
| Longitudinal travel | mm | 750(850manually) | 800 |
| Cross travel | mm | 400 | 380 |
| Vertical travel | mm | 400 | 360 |
| Quill travel | mm | 127 | 127 |
| Spinedle and Column distance | mm | 155-635 | 155-635 |
| Spindle and table distance | mm | 0-640 | 0-460 |
| Arm travel | mm | 400 | 500 |
| Milling head tilting | degree | 90(left right)45(front back) | 90(left right)45(front back) |
| Spindle taper | R8(V);NT80(H) | R8(V);NT80(H) | |
| Spindle speed | r/min | 66-4540(V);40-1300(H) | 66-4540(V);40-1300(H) |
| Spindle motor power | kw | 2.2(V);3(H) | 2.2(V);3(H) |
| Table load | kg | 350 | 350 |
| Overall size | mm | 1750x1530x2340 | 1750x1650x2340 |
| Net weight | kg | 1380 | 1550 |
Warranty:
What about the spare part if the machine break down?
==about the machine break down, normally our policy will be as the under way
1) Our quality guarantee time is 12 months since the machine on board
2) During this period, if the machine break down owing our machine itself quality problem, we will prepare the spare parts and send to you by free within 5 days. all these will be by free.
3) If the break down is caused by the mis operation, we of course will supply you the spare parts, but we have to charge you the costs prices.
Welcome to contact us!
Canthy Guo
Tengzhou Uni-tech Co. Ltd
Tel:0632-5810216 Fax: 0632-5810216
