Power module 125800-01

Product Details

Product Description

Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands
Power module

125800-01

Description The 4-Channel Relay Module is a full-height module that provides four relay outputs. Any number of 4-Channel Relay Modules can be placed in any of the slots to the right of the Transient Data Interface Module. Each output of the 4- Channel Relay Module can be independently programmed to perform voting logic. Each relay utilized on the 4-Channel Relay Module includes Alarm Drive Logic. Programming for the Alarm Drive Logic uses AND and OR logic, and can use alarming inputs (Alert and Danger statuses), Not- OK, or individual PPLs from any monitor channel or any combination of monitor channels in the rack. You can program this Alarm Drive to meet your application needs using the 3500 Rack Configuration Software. 3500/32M 4-Channel Relay Module Datasheet Bently Nevada Machinery Condition Monitoring 141533 Rev. T Specifications Inputs Power Consumption 5.8 watts typical Outputs OK LED Illuminated when module is functioning properly. TX/RX LED Transmit and Receive. Flashes to indicate proper communications between this module and other modules within the rack. CH ALARM LED Illuminated to indicate that the Relay Channel is in an alarm state. Relays Type Single-pole, double-throw (SPDT) relays Environmental Sealing Epoxy-sealed Arc Suppressor 250 Vrms, installed as standard Contact Life 100,000 cycles @ 5 A, 24 Vdc or 240 Vac Operation Each relay of the four channels is switch selectable for Normally Deenergized or Normally Energized. Environmental Limits Operating Temperature -30°C to +65°C (-22°F to +150°F) Storage Temperature -40°C to +85°C (-40°F to +185°F) Humidity 95%, non-condensing Physical Characteristics Main Module Dimensions (Height x Width x Depth) 241 mm x 24.4 mm x 242 mm (9.50 in. x 0.96 in. x 9.52 in.) Weight 0.7 kg (1.6 lb.) I/O Module Dimensions (Height x Width x Depth) 241 mm x 24.4 mm x 99.1 mm (9.50 in. x 0.96 in. x 3.90 in.). Weight 0.4 kg (1.0 lb.) Rack Space Requirements Main Module 1 full-height front slot. I/O Modules 1 full-height rear slot. Contact Ratings for Standard Systems Standard Relays Minimum switched current 100 mA @ 12 Vdc DC specifications (Resistive load) Maximum switched current 2 A @ 0V to 30 Vdc 0.75 A @ 48 Vdc 0.2 A @ 125 Vdc Max switched voltage 125 Vdc AC specifications (Resistive load) Maximum switched voltage 250 Vac Maximum switched current 2 A Maximum switched power 450 VA Contact Ratings For Functional Safety Systems and Hazardous Area Systems Standard Relays Minimum switched current 100 mA @ 12 Vdc DC specifications (Resistive load) Maximum switched current 2 A @ 0V to 30 Vdc Maximum switched voltage 30 Vdc AC specifications (Resistive Load) Maximum Switched Voltage 30 Vac Maximum Switched Current 2 Aect
