Plastic Water Drainage Dimpled Sheet Extrusion Machine/Waterproof China Production Line
| US$180,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
JS-PSB2000
Product Type
PE Board
Board Layers
Multilayer
Screw No.
Single-screw
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Customized
Customized
Condition
New
Delivery
45 Days
Width
2000mm
Screw Dia.
135mm
Output
400kg/H
Transport Package
by Film, Pallet, Containers
Specification
2000mm
Trademark
JUNSHENG
Origin
Jiaxing City, Zhejiang Province, China
HS Code
84778000
Production Capacity
20 Sets/Month
Packaging & Delivery
Package Size
3600.00cm * 280.00cm * 270.00cm
Package Gross Weight
36000.000kg
Product Description
Plastic Water Drainage Dimpled Sheet Extrusion MachineJunsheng Brand machines have passed CE certificate and exported to over 20 countries, like Turkey, Poland, Russia, Romania, Germany, Kosovo, etc.
Machine guarantee is 2 years and we offer Turn-key project.
Brief Introuction of Junsheng Waterproof Sheet Machine:
- Convex wall thickness of the circular convex on the drainage panel is well-proportioned.
- Compression strength is 50% higher than similar product, which solves the problem.
- Power saving 30%.
- Higher output
- Same forming roller, with changing different dimples, different sizes will be got.
- With changing mould, round and square shape.
- Drainage board thickness range is 0.5-5.5mm, width up to 5000mm.
Main Technical Specification of Junsheng Waterproof Sheet Machine:
| Model | PSB-2000 | PSB-3000 | PSB-4000 | PSB-5000 | |
| Screw dia. | mm | 135 | 150 | 180 | 150×2 |
| L/D ratio | L/D | 30:1 | 30:1 | 30:1 | 30:1 |
| Product width | mm | 2000 | 3000 | 4000 | 5000 |
| Product height | mm | 8, 10, 12, 15, 18, 20, 25, 30, 35, 40 | |||
| Output | Kg/h | 400 | 500 | 700 | 1000 |
| Line speed | m/min | 2-6 | |||
| Installed capacity | KW | 252 | 320 | 410 | 550 |
| Power consumption | KW | 132 | 160 | 220 | 300 |
| Dimensions (L×W×H) | m | 22×4×2.8 | 22×5×2.8 | 22×6×2.8 | 23×6×2.8 |
| Total weight | T | 16 | 20 | 28 | 35 |
