9 inch Fish pond plate bubble diffuser for oxygenation 300mm EPDM Air Disc Fine Bubble Diffuser

Product Description

Product Description
9 inch Fish pond plate bubble diffuser for oxygenation 300mm EPDM Air Disc Fine Bubble DiffuserAir disc fine bubble diffuser, which is used to transfer air and with that oxygen into sewage or industrial wastewater. Oxygen is required by microorganisms in the water to break down the pollutants. Air disc fine bubble diffuser series combines effective design, low installation costs, reliability and high performance in intermittent and continuous aeration processes.Special designed the slits cut opining, patterns and spacing between the slits for high oxygen transfer and longtime operation.The data sheet of bubble diffuser bubble disc diffuser have nomal size 200mm 215mm 260mm 300mm, the tube diffuser,diameter have 65mm or 90mm, length is customized, you can choose according to your request.Aerator Specifications215mm260mm300mmWorking ventilation1.5-3 m/h.pc2-5 m/h.pc2-8m3/h.pcService area0.3-0.65m/h.pc0.4-0.8m/h.pc0.5-1.0m/h.pcOxygen utilization rate22-40%31-59%35-59%Oxygenation capacity0.13-0.4kgO2/h0.21-0.4kgO2/h0.2-0.4kgO2/hSubmerged depth4-8m4-8m4-8mAir supply (water depth 4m)2m/h3m/h4.25m/hThe detail of fine bubble diffuserThe connector of fine bubble diffuser and saddle is standard size 22mm, and saddle have DN30,DN50,DN80 and so on, the saddle size is depend on the pipe you need in water treatment pond.Flat type disc fine bubble diffuser Arch type disc fine bubble diffuerThe production process and packing of fine bubble diffuser.The application of fine bubble diffuserRelated ProductsAny other question about fine bubble diffuser, please contact alisa freely, will professional service timely. Welcome iqnuiry.
