Timing Belt for Ceramic Industry

Product Description

(1)Specification: XL, L, H, XH, T5, T10, T20, AT5, AT10, AT20, 3M, 8M, 14M, S5M;
(2)It could be reinforced by steel wire core or kevlar core at option;
(3)All models teeth could be covered with green fabric and back covered with anti-rust latex. All items could be jointed endless.
(4)Made of thermoplastic polyurethane materials with high wear resistance;
(5)In the high-load transmission is still keeping good loading capacity;
(6)Opening belt could be continuous length, the middle and the sides are with parallel wire core;
(7)Aging resistance, water proof, working temperature -30 to 80, can endure maximum 110 in short time, can be combined with other thermoplastic materials
(8)Hard to be hydrolyzed, anti- acid, UV resistant, not aging, highly resistant to oil, anti-grease.
Application
Widely used in computer embroidery machine, beverage machinery, color glass and ceramics production and processing machinery, textile machinery and equipment industries. Its framework is with Stainless steel cord or copper wire reinforced and with high strength, low extension, good bend performance and the good characteristics of the load force.

Item	Pitch length ( MM )	Thickness (MM)	a(MM)	b(MM)	Angle
XL	5.08	2.3	1.27	1.03	50
L	9.525	3.6	1.9	1.7	40
H	12.7	4.3	2.29	2.01	40
XH	22.225	11.2	6.35	4.85	40
T5	5	2.2	1.2	1	40
T10	10	4.5	2.5	2	40
T20	20	8	5	3	40
AT5	5	2.7	1.2	1.5	50
AT10	10	4.5	2.5	2	50
T20	20	8	5	3	50
