Frc Solas Fiberglass Fast Rescue Boat with Outboard or Inboard Engine

Product Description

Product Description

Rigid Fast Rescue Boat China Manufacturer Tempsc Fiberglass SOLAS Marine FRC Rigid 9 Persons Water Fast Rescue Craft Boat with Davit Crane 60HP 90HP Outboard or Inboard Engine
AGI GROUP provides a series of Free Fall Lifeboat / Rigid Fast Rescue Boat or Totally Enclosed Life Boat for ocean-going tanker and cargo.
Types of lifeboat
*Totally enclosed Lifeboat/Rescue boat or Gravitational collapse lifeboat,20-120 persons
*Free Fall Life Boat 12-36 persons
*Rescue Boat 6 persons
*Fast Rescue Boat 6-12 persons
*Inflated Fender/Rigid Fast Rescue Boat
*Each vessel Match lifeboat standard:
Totally enclosed Lifeboat/Rescue boat(Gravity type): one ship, two enclosed lifeboat with davit
Free Fall Lifeboat:One ship,one free fall lifeboat
We Offer Others :
AGI49CF/FF Free Fall Lifeboat 20
AGI59CF/FF Free Fall Lifeboat 26
AGI67CF/FF Free Fall Lifeboat 23
AGI85CF/FF Free Fall Lifeboat 50
AGI105CF/FF Free Fall Lifeboat 64
AGI145FF(E406) Free Fall Lifeboat 77
AGI145CF/FF Free Fall Lifeboat 108
The 109CF/FF is an entirely new Free Fall Lifeboat designed for the oil platform.It has a very beautiful appearance and comfort
aboard of 68 persons.We hope this lifeboat can be used in more occasions.
145CF/FF is a Freefall Lifeboat with 77 persons specially designed to meet the lasted regulations for the Norwegian Continental
Shelf in the North Sea,the higher and more complex standard beyond SOLAS rules of Freefall Lifeboats.
Totally Enclosed Lifeboat Davits
*Gravity Luffing Arm Type Davit
*Hydraulic Luffing Arm Type Davit
*Telescopic Type of Lifeboat
*Platform Davit For Offshore Life boat
*Connecting Rod Type Davit of enclosed lifeboat
*Gravity Overhead Rolling Type Davit Of Lifeboat
Optional Equipment
*VHF
*SART
*EPIRB
*Engine heater
*Cabin heater
*Solar Charging
*AIS-SART
We understand the client's demand,even if you need the lifeboat with 100Kg of per person,we can also design elaborately for
you,make the totally enclosed lifeboat which meets your expectation. Product Parameters
Main Features Main material Rescue Boat is made of F.R.P. (Fire-Retardant). Approved marine watertight resin as adhesive and fiberglass cloth and mat as reinforced material are laminated in the female mold.
Suitable Davits :
Launching Appliance For Free Fall Lifeboat
Others Type Totally Enclosed Lifeboat Davits
* Gravity Luffing Arm Type Davit
* Hydraulic Luffing Arm Type Davit
* Telescopic Type of Lifeboat
* Platform Davit For Offshore Life boat
* Connecting Rod Type Davit of enclosed lifeboat
* Gravity Overhead Rolling Type Davit Of Lifeboa Main technical data Of 6.0m FRC Lifeboat

Principal dimension

1) Dimensions Length 6.00m Length over all 6.50m Breadth 2.20m Breadth max. 2.55M Depth 1.05m Height Max≈ 2.55M 2) Persons and Weight Unloaded Weight 1313kg 1353Kg 1408Kg Davit load with 3 persons 1560.5kg 1600.5Kg 1655.5 Kg Davit load with 6 persons 1808kg 1848Kg 1903 Kg Davit load with 15 persons 2550.5kg 2590.5Kg 2645.5 Kg 3) Person Person 3 - 15 4) Volume Total Volume 8.102 m3 Foam Volume 2.317 m3 5) Out board Engine Type B+S SOLAS YANMAR 160 144 236 Power 106KW 156KW 118KW Revolution 3800RPM 4300RPM 3300RPM Oil Capacity 175L 175L 175L 6) Speed Speed(3 Persons) ≥20 Knots Speed (15 Persons) ≥8 Knots

Others Models of the FRC Fast Rescue Boat

Model	Dimension (m)	Persons (P)	Speed c/w 3P (m)	Boat Engine	Total Weight (kg)
AG60KR	6.00x2.20x1.05	15	≥20	60HP	2418
AG60KR	6.50x2.30x1.05	15	≥25	90HP	2563
AG65KR	6.50x2.30x1.05	15	≥27	144HP	2599
AG65KR	6.50x2.30x1.05	15	≥27	160HP	2646
AG75KR	7.50x2.40x1.05	19	≥35	250HP	3200
AG85KR	8.50x2.80x1.10	22	≥35	250HPx2	5500

Packaging & Shipping
Packing of Enclosed Lifeboat
Different Color Of lifeboat Davit As your demands(Free Charge) Exhibition&Certification
Exhibition Of Enclosed Lifeboat
Company Profile
Why you Choose us
AGI GROUP was established in 1996 ,AGI Group has been a symbol of trust & quality for decades making it a pioneer in the lead Marine lifeboat manufacturing industry.
AGI has grown to be one of the global leaders in marine equipment industry,focus on a wide range,TEMPSC(Lifeboat) c/w davit appliance,marine prevention equipment(STP,OWS,Incinerator), Life-saving Appliance(LSA) &Fire-fighting Appliance(FFA),marine mooring equipment etc.for offshore vessels,offshore service and oil rigs. Certified by IACS(International Association classification societies) Class, such as CCS, DNV, ABS, BV, LR, RINA, NK, KR and RS etc. AGI products have been sold to many world-renowned ship owners, ship builders and ocean engineering projects, etc.
AGI offers complete system design,engineering,production,testing and lifelong service for all our products.Our well proven design ensure trouble free operations in harsh conditions and high reliability with a minimum of service required.
All the time,"Client First, Service Best" is our principle,providing them with strong support and fulfill all requirements for reliable and operational friendly equipment.Our mission is to make ship operations Greener, Safer and More Economical.
Successful Project Our 25 persons capacity enclosed lifeboat in Maritime Training Center Totally Enclosed Lifeboat in Vessel Fire-proof Type F.R.P Enclosed Lifeboat in Offshore or Platform Related Products For Totally Enclosed Lifeboat 1. Gravity luffing arm davit For Gravity lifeboat
This type is lowering lifeboat and rescue boat depending on boat self weight, and recovering the lifeboat and rescue boat using electric boat winch. the appliance is traditionally the most usually used life-saving and escape system that is safe and reliable.
2. The launching appliances for free-fall lifeboat
The launching appliances for free-fall lifeboat are specialized equipment for launching and recovering free-fall lifeboats.
3. The Single Arm Slewing Boat/Raft Davit for rescue boat or liferaft The Single arm slewing boat/raft davit is mainly used for lifting and lowering rescue boat, and also for lowering life raft.
Additionally, it is also acted ad crane bassed on client's requirement.
4. Platform davit is installed on offshore platform
Platform lifeboat davit which is lowering lifeboat and rescue boat depending on boat self weight, and recovering the lifeboat and rescue boat using electric boat winch. It's structure is simple and performance stalbe and reliable.
5. Rescue Boat lifesaving appliance("A" Type)
A Type Davit For Fast Rescue Boat,this lifesaving appliance is a special equipment used on board for launching and recovering a fast rescue boat. This appliance is provided with wave compensation unit, which meet with requirement for use on board the vessel.
6. Lifeboat winch and Release mechanism of lifeboat / Rescuse boat
Main Features The Lifeboat winch driven by electric motor belongs to a short time working equipment. The boat winch is of two kinds of structures, left-hand and right-hand boat winch which are symmetric. It can be suitable for arranging on the parent ship whose deck are symmetric. The boat winch is of the functions of hoisting boat by electric, lowering boat by gravity and hoisting boat by manual as well as manual quick lowering device for empty hook. The boat winch is provided with a manual driving unit which can automatically separate, and a interlocking switch. It can avoid the personal injury caused by mis-operation to the maximum. SIMILAR PRODUCTS Totally Enclosed Lifeboat Davits
* Gravity Luffing Arm Type Davit
* Hydraulic Luffing Arm Type Davit
* Telescopic Type of Lifeboat
* Platform Davit For Offshore Life boat
* Connecting Rod Type Davit of enclosed lifeboat
* Gravity Overhead Rolling Type Davit Of Lifeboat Certifications

IACS APROOVED FOR ALL OUR ENCLOSED LIFEBOAT Requirements Of Totally Enclosed Life Boat :
SOLAS 74 Convention as amended,Regulations III/4,X/3,III/21,III/31 and III/34
IMO Res. MSC. 48(66) amended by MSC.207(81),MSC.218(82),MSC.272(85) and MSC.320(89)
IMO Res. MSC. 36(33) -(1994 HSC Code)8
IMO Res. MSC. 97(73)-(2000 HSC Code)8
IMO Res. MSC. 81(70) amended by MSC.200(80),MSC.226(82),MSC.274(85) and MSC.321(89)
IMO MSC/Circ. 1006 and IMO MSC/Circ. 98
Our Equipment can meet the IACS (International Association Classification Societies) Class, such as CCS, DNV, ABS, BV, LR, RINA,NK, KR and RS etc.
Our mission is to make ship operations Greener, Safer and More Economical. World Wide Service System Just yours a telephone or an E-mail,we can know your demand in the shortest time.
Our specialized engineers and technical personnel will reply and satisfy your request soonest and rapidly provide technical explanation,all kinds of parts and accessories.
FAQ
Q1:Do you have the IACS Class Certificate ABS?
A1:Sure,our team had got all the IACS Class Certificate,such as ABS,RINA,EC,BV,NK,RS...
Q2:What is your team good at ?A2:we can dispatch all the goods you need,save the shipping cost for our clients.
One stop solution for our clients and professional exporter.
Q3:How about the payment?A3:We can communicate with each other,and get the best way.usually 30%TT (Telegraphic Transfer ) as deposit,70%TT before shipment.
Q4:Would you please help to apply the CO ( Certificate of origin of the lifeboat )?A4:Sure,if you need,we can apply the CO,form E. etc for our clients.
Q5:How long of the lifeboat's guarantee ?A5:usually 12 months for non-human damage factor.If any assistance,welcome to back our team. Free Fall Lifeboat 4.9m with davit Our Lifeboat System -Free Fall Lifeboat. We can manufacture the 4.9m free fall lifeboat for 20 persons and 6.7m free fall lifeboat for 33 Persons. Match the Launching Appliance of Free-Fall Life Boat. Rescue Boat 4.5m with davit We offer Rigid Rescue Boat 6 Persons and single davit for rescue boat with 25Hp outboard engine or inboard engine Fast Rescue Boat with davit We offer Rigid Fast Rescue Boat 9 Persons max 15 Persons and single davit or A type Davit for Fast Rescue boat with 60Hp outboard engine or inboard engine Lifeboat Systems We can offer: Free Fall Lifeboat Totally Enclosed Lifeboat Rigid Rescue Boat Fast Rescue Boat Partially Enclosed Lifeboat Tender Open Type Lifeboat Daughter Craft Custom Made Lifeboats Davit Systems Launching Appliance Of Free - fall Lifeboat Gravity Luffing Arm Type Davit Single Arm Slewing Boat Raft Davit Crane Rescue Boat Launching Appliance Platform Davit Hydraulic Luffing Arm Type Davit Telescopic Type Davit Connecting Rod Type Davit Gravity Overhead Rolling Type Davit Electric Boat Winch Crane Lifeboat Hooks Systems Delivered hook release system,refer to the Guide-lines for evaluation and replacement of Lifeboat release and retrieval systems ( MSC.1/ Circ.1392) Design and manufacture by the AGI GROUP and the hook release system comply with IMO resolution the resolution the MSC.320(89) and MSC.321(89) Key features: 35KN-120KN to choose Approved and Tested to IMO testing requirement set in MSC 1392 Cold water cutting,does not destroy the strength of the material itself Use of high corrosion resistance.High-strength raw materials Easy to control
