PLC Controlled Bobbin Winding Technology

Product Description

Winder with Automatic Bobbin Changeover System Upgrade your thread winding process with our Automatic Bobbin Changeover System from Jiangyin Langyu Machinery Equipment Co., Ltd. Enjoy seamless bobbin replacement and improved efficiency. Voltage: 380V. Warranty: 1 Year. After-sales support available online.
Application
Coated Fiber
Fiber multifilament
Aramid fiber
PBO fiber
UHMPEF
Polymide fiber
High performance ceramic fiber
Advantages
High quality winding package
Automatic bobbin change when reaching the target length and bobbin diameter
Arbitrary function of regulating the winding ratio
Yarn length setting
Alarm system (Yarn broken, bobbin diameter)
Wide range of application
Easy operation with reliable running
Technical Data For technical data, please contact Jiangyin Langyu Machinery Equipment Co., Ltd.

Model	LY203/254/300
Drive	Frequency-Controlled
Tension	100~2000g
Traverse system	Cam
Control system	PLC,HMI
Winding speed	200~600m/min Max
Max outer diameter	300mm
Tube Inner diameter	76/94mm
Tube length	215/280mm
Power supply	380V 60HZ
Winding ratio	Electric ,arbitrary function of regulating the winding ratio

Certification
Winder with Automatic Bobbin Changeover System Upgrade your thread winding process with our innovative automatic bobbin changer. Say goodbye to manual bobbin replacement with this advanced technology. Voltage: 380V. 1-year warranty included. Online support available.
