Crawler Crane 80 Ton Zoomlion New RC Crawler Crane Zcc850h

Product Description

As the only high-tech listed company incu bated from national research institute, Zoomlion is dominating the crowded crawler crane market by virtue of decades of technology accumulation of research and development on chassis, complete vehicle, structure and electro-hydraulic control and its professionalcrawler manufacturing base second to none in China. It has created many history records and surpassed dreams one after another. ZCC550H-1, ZCC750H-1, ZCC850H, ZCC1100H, ZCC1300, QUY180, ZCC1800. zCC2600, ZCC3800S, QUY 350, ZCC5000, QUY650, ZCC8800W. QUY800, ZCC12500, ZCC3200NP....
Our company:
Newindu E-commerce (Shanghai) Co., Ltd. is a leading Chinese construction machinery exporter, located in the downtown of Shanghai City. Since our company was founded, based on the advantage of the No. 1 Chinese construction machinery manufacturer, we continually introduce Chinese excellent construction machinery enterprises and their products to international markets, such as Changlin, Zoomlion, LiuGong, HOWO, Shantui, HBXG, YTO, SD LG etc. We not only make more international customers know and approbate our products, but also gradually build up friendship with construction machinery customers all over the world.
Out products:
1) ALL kinds of trucks.
(Dump truck, mining dump truck, tractor truck, truck trailer ,towing truck , water tank truck, concrete mixer truck, oil tank truck, garbage truck, cargo truck, port terminal tractor, refrigerated truck, truck mounted crane, fire truck, suction sewage truck, bus , etc)
2) All kinds of construction machinery.
(Wheel loader, excavator, folklift, cranes, paver, road roller etc.)
Need more information? Just contact me please!
Parameters: Item Unit Value Remarks

Max. lifting capacity × radius			t × m	80×4
Max. lifting capacity on fixed jib			t	7
Max. lifting capacity of luffing jib			t	15
Main boom length			m	13 - 58
Fixed jib length			m	6 - 18
Max. length of main boom with fixed jib			t	49+18
Luffing jib length			m	16m-34m
Max. main boom +max. luffing jib			m	43.5m+34m
Derricking angle			.	30 - 80
Fixed jib angle			.	10, 30
Max. rope speed of winches		Hoisting winch 1	m/min	125/110	With optional free-fall function
		Hoisting winch 2		125
		Derricking winch		93
Slewing speed			rpm	0-2
Traveling speed			km/h	0-1.57
Max. gradeability			%	30	With basic boom and counterweight over front
Ground pressure			Mpa	0.083
Deadweight			t	72.8	With basic boom
Crane counterweight			t	27
Overall dimensions(L × W × H)			m	13500×5000 (3400) ×3200	With A-frame and main boom pivot section
Engine		Model		WP10.270N	Weichai Power
		Rated power / rotational speed	kW/r/min	199/1900
		Max. output torque /rotational speed	Nm/r/min	1270/1200-1500
		Exhaust emission		National Stage II
Distance between track center × crawler contact length × crawler width			mm	2600 ×5440×800	Crawler carrier retracted
				4200 ×5440×800	Crawler carrier extended
Noise	Noise level outside operator's cab during operation		(dB)	≤107
	Noise level in operator's cab during operation			≤79

More pictures:
