Split/Separate Pressurized Water Tank for Solar Water Heater

Product Description

This Split pressruized water tank (stainless steel) is split from the solar collector, no more worries about the rusting. And it can be put anywhere inside the house.

Model	IPWT-100	IPWT-150	IPWT-200	IPWT-250	IPWT-300	IPWT-400	IPWT-500
Capacity(Liters)	100L	150L	200L	250L	300L	400L	500L
Inner Tank Dia.	Φ 370	Φ370	Φ470	Φ470	Φ470	Φ600	Φ600
	Φ368	Φ438	Φ542	Φ542	Φ613	Φ613	Φ613
Outer Tank Dia.	Φ470	Φ470	Φ560	Φ560	Φ560	Φ700	Φ700
	Φ450	Φ520	Φ620	Φ620	Φ710	Φ710	Φ710
InnerTank Material&Thickness	SUS304 1.2mm	SUS3041.2mm	SUS3041.5mm	SUS3041.5mm	SUS3041.5mm	SUS3042.0mm	SUS3042.0mm
	Enamel BTC340R 1.8mm	Enamel BTC340R2.0mm	Enamel BTC340R2.0mm	Enamel BTC340R2.0mm	Enamel BTC340R2.5mm	Enamel BTC340R2.5mm	Enamel BTC340R2.5mm
Outer Tank Material&Thickness	White Color Steel 0.55mm
Insulation Layer Thickness	50mm	50mm	45mm	45mm	45mm	50mm		50mm
	40mm	40mm	40mm	40mm	40mm	40mm		40mm
Copper Coil Inlet&Ooterlet Size	1/2'
Inlet&Ooterlet Size	3/4'	3/4'	1'	1'	1'	1'		1'
Heat-exchange area of upper	None	0.4	0.4	0.4	0.4	0.5		0.5
Heat-exchange area of bottom	0.6	0.6	0.6	0.7	0.7	0.8		0.8
Subsidiary heating power	2.0KW	2.0KW	2.0KW	2.0KW	2.0KW	3.0KW		3.0KW
Water Tank Size(mm)	Φ47*104	Φ47*144	Φ56*125	Φ56*152	Φ56*181	Φ70*154		Φ70*185
	Φ45*111	Φ45*157	Φ52*153	Φ62*128	Φ62*153	Φ71*158		Φ71*172
Packing	55*55*112	55*55*150	64*64*133	64*64*158	64*64*187	78*78*163		78*78*195
	48*48*120	48*48*167	55*55*163	66*65*138	66*66*163	74*74*168		74*74*180
Accessories	Magnesium rods,P/T valve,Drain water valve,Ckeck-pressure reduce valve

Automatic Workshop
1.Modern workshops have advanced production lines and professional knowledge of assembly.
2.Flow card to record each details carefully.
3.100% self-inspection before packing.
Advantages
1.Economic and practical products from Sunlight , reliable performance.
2.Choose Sunlight, choose a rest assured.
3.Advanced production lines and test rooms.
4.Perfect QCP.(Quality control plans)
Application: car, truck, bus, cooler room
Packaging & Shipping
Strong packaging to ensure safety during transportation.
Export wooden box packaging for products.
FAQ
Q1.Can I have a sample for testing?
A: Yes,of courses we can supply the sample for you !
Q2.Can I add my logo on the water tank?
A:Yes,OEM and ODM are available for us.But you should send us LOGO image.
Q3. How can i get the after-service?
A:We will send you the spare parts by free if the problems caused by us.If it is the men-made problems,we also send the spare parts,but you should pay.
Q4.Do you have inspection before delivery?
A:100% self-inspection before packing
Q5.Can I have a visit to your factory before the order?
A: Sure,welcome to visit our factory.Here is our factory address:No. 5 Shengda Road, Konggang Industrial Park ,Luoxi Town, Xinbei District, Changzhou City, Jiangsu Province China
