Hydraulic Telescopic Spreader Container Lifting Equipment 40.5t

Product Description

Container Spreader
Container spreader is attached to crane by hook, the twist lock is controlled by lifting wire rope. There is no need for crane operator to articulated/decoupling. Easy installation and save more transformation time from the hook to container. It can work without electric and no need to update crane control circuit.
Applied to ISO container: 20ft, 30ft, 40ft, 45ft, 53ft.
Capacity: from 10t to 45t.
Ambient temperature: -20ºC ~ +45ºC
Twistlock: IOS floating twist-lock, driven by automatic spring.
Flippers Device: Unpowered fixed flippers.
Technical Parameter

Item: Hydraulic Telescopic Spreader Container		Spring stroke	100 mm
For operation with ISO standard 20' or 40' containers		Ambient temperature	-20ºC ~ +45ºC
Rated lifting load	35t	Twistlock mode	Linear actuator heavy hammer type automatic resell way
Dead weight	4.9t / 6.9t	Flippers device	No power, fixed flippers
Allowable load eccentricity	± 10%	Application	Portal crane,gantry crane,crane in the plant

Note: The above parameters for the performance of the existing cases of mature technical parameters are for reference only.
We can design and manufacture products according to user's requirements. There are various derivative models of said crane available for customers to choose.
About us:
Jiangsu Tonghui Lifting Equipment Co., Ltd. (THHI) Is located in Wuxi City, Jiangsu Province, near the scenic Taihu Lake. As a subsidiary company of Wuxi Jiangnan Mining Machinery Manufacturing Co., Ltd., the company specializes in manufacturing, processing and marketing of port lifting equipment, marine handing equipment, marine engineering special equipment, material handing equipment, non-standard metal structural parts and so on. It can meet the need of various projects.
The company now has more than 20 professional engineers and technicians with high and intermediate titles and more than 100 professional technicians of various types of work, which can meet the need of the company's current corresponding engineering projects. The company covers an area of more than 15,000 square meters, with 11,000 square meters of production workshop, 2,000 square meters of test site and 1,000 square meters of office complex building. There are more than 10,000 square meters of steel structure production base, machining workshop and more than 100 sets of sophisticated equipment and various complete testing instruments. The company has strong technical force and complete testing means. The whole process of the company's operation strives to implement the quality assurance system of ISO 9001:2008 standard.
THHI provides:
Designs to customer specification, including volume and weight. Fast spare-parts delivery across the world. Acceptance testing including certification such as BV, LRS, GL, ABS, and etc.
Our advantage: As a leading manufacturer of 5000 square feet dedicated, licensed and certificated staff. Mechanical and machinery design, structural design and analysis dynamic modeling and seismic, failure modes and effects analysis Auto CAD, 3DMax, Math CAD, Solid Works, ANSYS and SAP2000 Advanced. All Main parts using reliable original imported brand.
Our Certificates:
THHI provide the SGS, CCS, BV, CE, ABS, ISO9000:2008, ISO14001:2004, OHSAS and etc certifications, also accept third party inspection, such as SGS Factory test etc.
What the CCS, BV, CE, ABS, certificates indicates: All the product design drawing and calculation is reasonable and meet the international standard, all the productions drawing and calculation will be audit before production. The welding meet the international standards, and no damage detection reports are required. On the testing the actual lifting capacity is 1.25 times than the rated lifting capacity and will issued exactly testing report according to the technical agreements.
FAQ:
Q1: What's the information should I provide when inquiry?
A: Thanks for your question. The more information you provide, the more accurate solution we can prepare for you! The information such as the lift capacity, span, lift height, power source or other specials you give us will be more appreciated.
Q2: Is your products customized?
A: Yes, because of the different working condition, all our products are customized depending on detail requirement! So if you give us more information about the lift capacity, span, lift height, power source and other specials, we will give you a very quick quote!
Q3: How can we install the crane?
A: Our senior engineer can be your side to provide the installation guide service and training. Moreover, our best sales can visit your country.
Q4: Can you provide the serious lifting tools?
A: Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, magnet or other specials as your requirement!
Q5: How about your payment terms?
A: we accept T/T and L/C at sight.
