80GHz 260 Meters Dtam D29-V Radar-Video Fusion Microwave Detector

Product Description

DTAM D29-V radar-video fusion microwave detector is a traffic sensing device independently developed by our company. It has the characteristics of wide detection range, high detection accuracy, and stable detection performance. It can cover 8 lanes in both directions and has a maximum detection length of 260 meters. The radar uses the industry's most advanced traffic target tracking algorithm, which can achieve real-time identification and accurate tracking of 256 targets in the area. Even in high-density, low-speed environments, it can still maintain excellent detection results. In addition, this radar integrates a video module, which can realize all target information detected by the radar, superimposed on the video image in real time, and can be reused for intersection monitoring, with one machine for multiple uses.
Product Parameters
Radar parameters:

No	Specifications	Parameters
1	Operating frequency	80GHz
2	Detection range	8 lanes in both directions; 260m in longitudinal direction
3	Simultaneous Detection	256
4	Detection Range	260m
5	Range accuracy	0.1m (near beam)/0.4m (far beam)
6	Range resolution	0.39m (near beam)/1.79m (far beam)
7	Range of Speed Coverage	-200km/h~+200 km/h
8	Speed accuracy	0.1km/h
9	Velocity resolution	0.43km/h (near beam)/0.37km/h (far beam)
10	FOV	Near beam 120° (horizontal)/20° (vertical) Far beam 18° (horizontal)/14° (vertical)
11	Angle accuracy	0.3° (near beam)/0.1° (far beam)
12	Angle resolution	3.2° (near beam)/1.6° (far beam)
13	Operating temperature	-40ºC~70ºC
14	Operating voltage	DC 24V(Wide voltage range: 16~36V)
15	Operating humidity	0~95%
16	Power consumption	≤12W
17	Installation height	6~8 meters

Video parameters:

No	Specifications	Parameters
1	Sensor	1/2.8 inch CMOS
2	lens	12mm fixed focus lens
3	Pixel	500W
4	Video FOV	26°
5	Image format	JPEG
6	Video protocol	Supports docking with ONVIF protocol and national standard G28181 protocol
7	Network protocols	Supports TCP/IP, HTTP, DNS, RTP, RTSP and FTP transfer
8	Mini illumination	Color 0.1Lux@(F1.2,AGC ON) Black and white0.01Lux @(F1.2,AGC ON)
9	Max resolution	2592*1944
10	Compression standards	H.265/H.264/MJPEG
11	Video frame rate	Mainstream:2592*1944 2560*1440 1920*1080 1-20 fps Sub-stream: 1280*720 704*576 640*480 352*288 1-20 fps
12	Output bit rate	16kbps~20Mbps adjustable
13	Structured attributes	Supports license plate recognition, including license plate color recognition, license plate type recognition, license plate number recognition, supports 10 Arabic numerals "0-9"; 26 English characters "A-Z"; recognition of Chinese character abbreviations for provinces and municipalities; Chinese character recognition for license plate classification; Supports vehicle type recognition, including cars, vans, light buses, medium buses, large buses, buses, mini trucks, light trucks, medium trucks, large trucks, heavy trucks, forklifts, etc.; supports vehicles color recognition.

Installation Instructions 1. Intersections
The types of intersections in the city include: crossroads, T-intersections, and multi-fork intersections (more than 4 roads). There are two ways to install an intersection:
1. The radar is installed on the signal light pole to observe the oncoming lane;
2. The radar is installed behind the electric pole to observe the oncoming lane.
Method 1: Installation and deployment of signal light poles
Method 2: Installation and deployment of electric poles
2. Tunnels
Tunnel scenes are usually hoisted at the top of the tunnel to detect the direction of vehicles.
Our Advantages The detector has high range and speed resolution, accurate vehicle positioning and accurate speed measurement. Achieve multi-lane detection, track vehicles in different lanes, and accurately detect their speed and position. The detector adopts a "radar + video" integrated design, and the multi-sensor fusion mode can support multi-target radar tracking, video forensics, coordinate matching, and data fusion functions. It covers up to 8 lanes horizontally and 260 meters vertically, enabling large-area detection. It covers the functions of traditional microwave vehicle detectors and can provide information including: vehicle speed, traffic volume, headway, vehicle type classification, road occupancy rate and other information. Detection accuracy: traffic flow accuracy: ≥95%; queue length accuracy ≥90%, event accuracy ≥95%. It can count the length of queued vehicles and provide queue overload event information. According to the vehicle trajectory, it can judge traffic abnormalities such as vehicle reversal and lane change. It can detect pedestrians, non-motor vehicles and motor vehicles. The radar has a real-time clock that can be synchronized with the network clock. The radar has the ability to work all day and night and is not affected by light and weather such as rain, snow and fog. Applications DTAM D29-V radar and video microwave detector has the functions of stable tracking of group vehicle trajectories, vehicle feature recognition, traffic flow information collection and statistics, traffic event detection and recognition, etc. It is suitable for various complex traffic scenarios such as "large traffic volume, mixed traffic of motor vehicles and non-motor vehicles", and can be widely used in urban intersections, expressways, highways, bridges, tunnels and other road scenes, providing scientific, advanced and comprehensive intelligent traffic perception solutions for urban signal control, smart expressways, traffic digital twins, vehicle-road collaboration and other systems.
Expressway Application Solution:
Tunnel Application Solution:
Bridge Application Solution:
