Heli Hangcha JAC Komatsu Zoomlion Lonking Huahe 3ton 4ton 3m 4m 4.7m 5m Diesel Forklift Electric Forklift Trucks Forklift Lithium Forklift Hydraulic Forklift

Product Description

Heli Hangcha JAC Komatsu Zoomlion Lonking Huahe 3ton 4ton 3m 4m 4.7m 5m Diesel Forklift Electric Forklift Trucks Forklift Battery Forklift Hydraulic Forklift
Products Features
A larger underground clearance of the chassis may overcome many kinds of complex terrain working.
The off-road mobility is enhanced through by driver wheels with the MPT multi-function tires, wide base and cross-country tread pattern.
Uses the integral-type combination instruments, the fuse box places in left side of the steering wheel, which advantage for the replacement, also installed with a cigar lighter.
Lower pollution
High efficiency hydraulic system decreases the fuel consumption;
This lift truck is equipped with high performance engine to meet EU EC and USA EPA new regulations.
Ergonomics Improved
Right located control lever effectively reduces driver's arm tiredness;
Make the operator get wider and better visibility through creative and optimal design for the box iron, cylinders, chain of mast;
The operator's legroom is twice to other series with optimized construction;
Conveniently behavior with electro-hydraulic direction changing lever and automobile type double joystick combined switch;
Reliability Improved
Automatic monitor control system could ensure the monitor working stably and safely;
The high strength special-shaped overhead guard is designed to ensure the safety;
Applying the park brake system safety protection device, avoid the hidden danger caused by faulty operation;
Safety wire harness, Reliability and good Maintainability;
More safety operation with the OPSS system;
Lower damping device inside the lifting system reduces mast shock and vibration, improving the whole truck's safety and reliability.
Product Parameters

ORKLIFT SPECIFICATIONS
No.	Specifications			Unit	CPCD30
1	Characteristics	Power			diesel
2		Rated Capacity		kg	3000
3		Center of load		mm	500
4		Lifting height		mm	3000
5		Free lifting height		mm	145
6		Forks L×W×H		mm	1070x125x45
8		Min.turning radius		mm	2400
9		Min.ground clearance(Mast)		mm	110
10		Overhead guard height		mm	2138
11		Front overhang		mm	943
12	Perf	Max.traveling speed(loaded)		km/h	483
		Max.traveling speed(loaded)		km/h	20
13		Max.lifting speed(loaded/empty)		mm/s	470/520
14		Drawbar pull/Gradeability		kN/%	18/20
15	Dimensions	Overall length (without fork)		mm	2695
16		Overall width		mm	1230
17		Mast lowered height		mm	2055
18		Mast extended height		mm	4256
19	Chassis	Tire	Front		28x9-15-12PR
20			Rear		6.50-10-10PR
21		Wheelbase		mm	1700
22		Tread width	Front/Rear	mm	1000/970
23		Curb weight	None-load	kg	4350
