Plastic Pet Bottle Recycling Line
| US$50,000.00-150,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
1000 kg/h
Screw
Single-Screw
Automation
Automation
Computerized
Computerized
Certification
ISO9001:2008
Capacity
500-2000kg/H
Post Service
Overseas Service Center Available
Screw Type
Single Screw
Speed Control
Inverter
Material
SUS304
Motor
Made in China
Reducer
Made in China
Crusher
2sets
Float Washing
4sets
Friction Washing
2sets
Dehydrator
1set
Transport Package
Film Packing
Specification
ISO9001: 2000
Trademark
LANHANG
Origin
China
HS Code
8474
Production Capacity
50 Sets/Year
Product Description
Specifications
PET waste bottle recycling line
High automation
Perfect synchronized
Customized process solutions
Overview
To separate PET bottles to flakes from PE/ PP label, cap, oil, garbage, protect the environment, avoid white pollution.
Recycled PET can be used again to produce PET-based plastic products, e.g. bottles (not food & beverage-grade), fiber/cloth, sheet, strap band and, etc.
Range Available:
Input capacity | 500kg/h | 1000 kg/h | 2000 kg/h |
Workshop(M*M*M) | 42 (L)×10(W)×6(H) | 55(L)×15(W)×6(H) | 70(L)×18(W)×6(H) |
Manpower | 6 Persons | 8 Persons | 12 Persons |
Installation power | 156KW | 307KW | 420KW |
Water Consumption: | 2 Ton/h | 3.5 Ton/h | 5 Ton/h |
Features:
The whole line is fully automatic and it has characteristics of high efficiency, low noise and easy operation.
The line can easily wash and recycle waste PET bottle flakes ,which includes PE/PP labels, PVC labels, paper labels, HDPE cups, glue, mud, beverage leftover, oil, and scrap iron.
It adopts hot water washing to get good quality. Various output capacities can be chosen: 500kg/h, 1000kg/h, and 2000kg/h(Customized).
The degree of cleaning is as much as 96% and the degree of drying is as much as 98%.
Main List And Function:
No. | Item | Qty | Remark |
1 | Bale Breaker | 1 Set | Cut And Break Packaged PET Bottles |
2 | Belt Conveyor | 1 Set | Conveying Bottles |
3 | Screening Machine | 1set | Filtering Sand, Dirty, Impurity |
4 | Belt Conveyor | 1set | Conveying Bottles |
5 | Label Remover | 1 Set | Removing Label From Surface Of Bottle Label Removing Efficiency: 90%-95% |
6 | Manual Sorting Table | 1 Set | Sorting Different Plastics By Manually |
7 | Metal Detector | 1set | Detecting Metal, Aluminum, Stainless Steel And So On Automatically |
8 | Belt Conveyer | 1 Set | Conveying Bottles |
9 | Wet Crusher | 1 Set | With Water, The Material Of The Blade Adopt Skd-Ii Or 9crsi |
10 | Screw Feeder | 1 Set | Conveying Flakes |
11 | Twin Screw Floating Washer | 1 Set | Washing And Separate PP Caps/Label According To Different Specific Gravity |
12 | Screw Feeder | 1 Set | Conveying Flakes |
13 | Hot Steam Washer | 1 Set | Removing Oil By NAOH And Hot Washer Or Hot Steam |
14 | Screw Feeder | 1 Set | Conveying Flakes |
15 | Friction Washer | 1 Set | High Friction Efficiency By High Speed, Adopt Germany Technology |
16 | Twin Screw Floating Washer | 1 Set | Washing And Separate PP Caps/Label According To Different Specific Gravity |
17 | Dewatering Machine | 1 Set | High Dewatering Efficiency By High Speed, Adopt Germany Technology, Water Content 5% |
18 | Label Separator | 1set | Separating Leftover Label From Pet Flakes |
19 | Drying System And Storage Hopper | 1 Set | Drying By Electric, Water Content ≤2% |
20 | Electrical Control Cabinet | 1 Set | Adopts ABB , SIEMENS And OMRON As Main Electric Component. |
