US$3.54
1,000-1,999 Pieces
US$3.43
2,000-4,999 Pieces
US$3.37
5,000-9,999 Pieces
Basic Info.
Usage
Switching, Mobile Phone, Game
Certification
TUV, RoHS, ISO9001, CE CB
USB Output
5V/3A, 9V/3A, 12V/2.5A, 15V/2A, 20V/1.5A
Type-C Output
5V/3A, 9V/3A, 12V/2.5A, 20V/1.5A
Lead Time
About 25 Working Days
Transport Package
Carton Box
Production Capacity
1000000pieces/Year
Packaging & Delivery
Package Size
5.50cm * 4.50cm * 9.00cm
Package Gross Weight
0.050kg
Product Description
Product Description
Universal AC input/Full range(up to 264Vac) Small Size: 44*39*27mm Operating Temperature: -10ºC to 40ºC,Full load, Normal operation Protection: Short Circuit/Over Current/Overshoot High efficiency Fast charging 100% full load burn-in test Meet CE CB Approved At 25ºC,in full load,the life will more than 20,000 hours Two years warranty
Detailed Photos
Products Show:
Product Parameters
Product Name | EU plug 30W Fast Charger Power Adapter for Cell/Mobile Phone |
Input Voltage | 100-240V 50/60Hz |
USB Output | 5V/3A,9V/3A,12V/2.5A,15V/2A,20V/1.5A |
Type-C Output | 5V/3A,9V/3A,12V/2.5A,20V/1.5A |
Power range | 30W PD Max |
Certificate | CE CB |
Aging Test | 100% |
Short Circuit Protection | Shall be protected when any output operation in circuit short condition, Over load |
Over Current Protection | Yes |
Over Voltage Protection | Yes |
Operating Temperature | -10ºC - 40ºC,Full load, Normal operation |
Output connector | A,Type-C,A+C |
Product Size | 44*39*27mm |
Material | ABS&PC |
Warranty | Two years |
Factory Shows
Production Workflow Chart
Production Workflow Chart
Welcome to visit our factory!
Certifications
FAQ
Warm Tips:If you don't find the exact product which you need from our website,feel free to contact us directly,we have a professional technical team and service team,we have ability to customize your products according to your requirements!
