Hot Selling Precision Gear Head Lathe Metal Bed-Type Milling Machine in Europe

Product Description

Product Parameters

MODEL			UNIT		SPE.
Table size(L×W)			mm		2100×500
T-slot (WIDTH×NO.)			mm		20×4
Max. travel	Longitudinal		mm		1500
	Cross		mm		600
Feed speed of Longitudinal and cross	Speed range		mm/min		2.5~3000
Rapid feed speed			mm/min		6000
Max load of table			Kg		2000
HEAD
Distance from spindle nose to table surface	Vertical spindle		mm			0~650
Distance from spindle axis to table surface	Horizontal spindle		mm			8~660
Feed speed of Z axis	Speed range		mm/min			2.5~2500
Rapid feed speed of Z			mm/min			3000
SPINDLE
Distance from spindle axis to column guideway			mm			610
Spindle speed	step					12
	Speed range		rpm			35~1345
Spindle taper			ISO50			7:24
MOTOR
Spindle drive motor		kw		7.5
Feed motor		kw (AC)		2.5(Y,Z) 1.4(X)
Coolant pump motor		w		550
Lubricant pump motor		w		120
Overall size		mm		3650×2380×2750
Machine weight		kg		7300

Company Profile
Certifications
Exhibition
Packaging & Shipping
FAQ
FAQs
Q1: How is the warranty?
A1: Warranty time is 15 months after BL date.
Q2: Can we visit your factory before order?
A2: Sure. All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3: Do you have a stock?
A3: We have stock for popular models, we produce according to order.
Q4: What's the MOQ?
A4: One set only.
Q5: How about your quality?
A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 40 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6: Do you have professional engineers?
A6: Yes, we have professional engineers and designers. We can provide OEM services under Alpha brand.
Q7: Can you provide customized machines?
A7: Yes, we can design and manufacture according to your specific requirements.
