High Performance Semi-Auto Fire-Fighting and Explosion-Proof Detection Robot

Product Description

Dimensions	<1600*1400*1300mm
Total weight	<800kg
Obstacle crossing height	>220mm
Climbing ability	>70%
Remote distance	1000m
Straight speed	>1.5m/s
Straight running deviation	<7%
Braking distance	<0.3 m
Spray cooling device	Yes
Anti-overturn function	Yes
Anti-collision function	Yes
Gas collection	6 toxicf and flammable gases
Waterproof	IP 67 chassis,top IP65
Working time	>5h
Load capacity	80kg
Ability to tow hose	2 80 water hose 100 meters
Drive control method	Wireless control,redundant control
Slope	>30°
Wiorking pressure range	1.0Mpa
Pitch angle	<-5°,>+90°
Turning angle	<-90°,>+90°
Range	Water >80m,foam mixture >80m
Flow	80L/s
Operating Voltage	DC12V
Average relative humidity	<95%(±25ºC)
Signal System	PAL/AHD or RJ45
PTZ performance	Initial height<1500mm,height after lifting >1900mm

Q:Could your company modify the standard product depends on my request?
A:Yes. Our company is specialized in researching and designing various of special purpose vehicle and
spare parts. We can provide any product according to your demand.
Q:Can I customize the painting and logo?
A:Yes,of course, we can paint the truck as your requirements.
Q:What's your quality guanrantee or after sales service?
A:Our guarantee is 1 year, the key parts damage not caused by improper operation, it will free maintenance
and replacement. And we also provide online support, Video technical support and spare parts available. Contact us TERA foreign trade department
