ZRJ-30 Vacuum Homogenizing Emulsifying Machine

Product Description

ZRJ series Vacuum Homogenizing Emulsifying Machine
Instruction and features:
Application:
The equipment is suitable for emulsification of the pharmaceutical. Cosmetic, fine chemical products, especially the material having high matrix viscosity and solid content. Such as cosmetic, cream, ointment, detergent, salad, sauce,lotion, shampoo, toothpaste and so on

Structure Drawing:

Structure:
this homogenizer include main pot, water and oil pot, vacuum system, lift system, temperature system, control system and so on
Principle:
First put the raw material which can dissolved into water into water pot, then heat it , and mix it
Second: put the raw material which can dissolved into oil to oil pot, heat it and mix it,
Then suck both of the raw material into main pot, to homogenize the two material by homogenizer

Character:
Control by computer touch-screen, integrated operation, with beautiful generous;
Work continuously large quantity, circulating homogeneous discharging, especially suitable for single products continuous production
Easy operation, perfect homogeneous emulsification
Capacity : 100-2000L
Helical ribbon mixing, internal external circulating homogenization.
Product Prameters:

Model	Volume	Emulsify		mixer		Outside dimension
		Kw	r/min	Kw	r/min	L	W	H	M H
ZRJ-30	30L	1.5	0-3500	0.75	0-70	1500	800	1500	2050
ZRJ-50	50L	3	0-3500	0.75	0-70	2750	2100	1900	2600
ZRJ-100	100L	3	0-3500	1.5	0-70	2800	2150	2100	2800
ZRJ-150	150L	4	0-3500	1.5	0-70	2850	2150	2150	2900
ZRJ-200	200L	4	0-3500	1.5	0-70	3000	2200	2200	3100
ZRJ-350	350L	5.5	0-3500	2.2	0-70	3650	2650	2550	3600
ZRJ-500	500L	7.5	0-3500	2.2	0-50	3800	2800	2700	3950
ZRJ-750	750L	11	0-3500	3.7	0-50	3900	3900	2900	4400
ZRJ-1000	1000L	11	0-3500	3.7	0-50	3900	3400	3150	4550
ZRJ-2000	2000L	22	0-3500	7.5	0-50	4850	4300	3600	4800
