Hand Winch Manual 3.2t Wire Rope Pulling Hoist

Product Description

3200 KG Wire Rope Pulling Hoist
1.Forward and reversing levers in tandem provide slim design and assure power transfer along the center line.
2.Overload protection is by a shearing pin in the forward lever,Spare shear pins are conveniently located in the carrying handle or operating lever.A broken pin can be replaced without removing the load.
3.A lever disengages the rope clamp system allowing easy,smooth installation of the wire rope.
4.The parallel arrangement of the clamping system protects the wire rope by distributing the clamping forces evenly.A long rope advance per each lever stroke increases the working speed.
5.The large opening in the top of the unit allows easy cleaning:simply flush the unit with water,apply motor oil for lubrication and the puller is again ready for use.

3200 KG wire rope pulling hoist specifications
Model	Y-3200
Rated Capacity(KG)	3200 kg
Wire Rope DIA (Ø in mm)	16.0mm
Wire Rope Safety Factor	5.0
Static Load Safety Factor	4.0

packing and loading
FAQ
1. How to order the products?
Send the inquiry with detail item description or with ITEM number. Tell us the quantity you need, the size of goods, and the packing. If there is no packing demand we take it as seaway packing. If possible please attach one reference picture to avoid any misunderstanding or any links from our website for we get a better understanding.
2.How about sample ?
Cost with free if the quantity small, and the express charge account into buyer's.
3.How about the prodution time ?
Cause all of our products manufacturer according customers order, usually within 35days after receipt of your deposit.
4.How will my order be shipped?
Usually shipped by sea, small order or urgent order can by air or by courier after received your agreement.
5.How about the mini order ?
Different products with different limited, please contact us to confirm.
