Made in China 6*6 Compressed Garbage Truck 28-30 Cubic Meter Garbage Truck Price Garbage Truck Price

Product Description

Product Description
Chinese Factory Sinotruk 30m³ garbage compactor truck
Garbage Compactor Truck, also called Compressed Garbage Truck, Compactor Garbage Truck, Compressed Garbage Truck, Rear Loader Garbage Compactor Truck, Waste Compactor Truck, Waste Compressed Truck, Refuse Compactor. How the Garbage Compactor Truck Works? The garbage compactor trucks are loaded by sanitation engineers along neighborhood streets. The trash is loaded into a hopper in the back of the truck of rear loaders. Hydraulic cylinders operate the compacting mechanism, which takes the trash out of the hopper and places it into the body of the truck. How much does a Garbage Truck hold? Different types of garbage trucks that hold different amounts of waste. The truck that comes through your neighborhood can hold anywhere from 5 tons to 22 tons of waste. The available chassis brands for Garbage Compactor Truck areSINOTRUK, DONGFENG, FAW, FOTON, JAC, JMC, HYUNDAI, etc.
The car is a mature product of our company, the top part is composed of sealed garbage compartment, loader, shovel, hydraulic transmission system and electrical control system. The whole vehicle is fully sealed, using electro-hydraulic integration technology, with the help of machine, electricity, hydraulic combined automatic control system, through the compartment, filler and push shovel and other special devices, to achieve garbage pouring, crushing or flattening, strong loading, the garbage into the compartment and compacting and discharging. All the sewage in the process of compression enters the sewage compartment, which completely solves the problem of secondary pollution in the process of garbage transportation. vehicle disposition
The vehicle is composed of car chassis, garbage box, filler and turnover mechanism, the vehicle load part is made of Q345 high strength manganese steel, volume of about 30 cubic meters, can load 18-20 tons of bulk domestic garbage, the car with two-way compression function, the middle and rear sewage tank, the latest brokenable wood function, China's especially famous brand hydraulic system, There are electronic control automatic operation functions inside the cab and outside the vehicle, and different garbage loading devices can be optional at the rear of the vehicle.
Product Parameters

Overall dimens ions:	11100×2550×3400(mm)	Container size:	××(mm)
Total mass:	31000(Kg)	Approach/depa rture Angle:	16/13 (.)
Rated quality:	13750 (Kg)	Front overhang rear overhan g:	1450/2905(mm)
Quality of servi ce:	17000(Kg)	Maximum spee d:	89,110 80 (km/h)
Chassis parameters
Type of fuel:	Diesel	Chassis mode l:	ZZ53**XXYN504GF1
Number of axl es:	4	Front wheel ba se:	1998,2035 (mm)
Wheelbase:	1800+4600+1350	Rear wheel ba se:	1850/1850(mm)
Cab passenger number:	3(people)	Number of spri ng pieces:	3/4, 3/5, 3/10, 11, 10, 11, 1 2, 3 / - / -
Number of tire s:	12(tires)	Axle load:	9.5000/16000
Tire specificati ons:	12.00R20 16PR,11.00R20 18PR,12R22.5 18PR,295/80R22.5 18PR,315/80R2 2.5 18PR/315/80R22.5 16PR

other	Air brake ABS air conditioning, other FOTON chassis standard.
Special configuration parameters:
Box effective volume	About 30 m after
Body shape	The new arc
The body material	Q345 manganese steel (side 5base 5)
Compression ratio	2.5 or higher
Effective volume of filler	After 1 m or higher
Loading cycle time	25 or less s
Feeding cycle time	15 or less s
Garbage time	35 s or less
The control mode	Automatic, manual
Hydraulic system pressure	18MPa
Multiple directional control valve	Jiangsu oil valve
Hydraulic oil pump	Hefei pump
Conversion force retractor	Zhejiang jiashan
Electronic control system (PLC one-button cycle)	Taiwan imports
Engine power control	Fully automatic control

Other dedicated features

1, new can be broken scraper 2, with bidirectional peristaltic compression function 3, with middle and rear double sewage tank 4, push shovel slider, slide slider are high quality MC nylon 5, filling device lifting cylinder is equipped with a balance valve 6, body high profile light/side light/operation light
