VTC850 high quality Conventional Single Column CNC Vertical lathe machine price
Basic Info.
Model NO.
VTC850
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools, CNC Non-Conventional Machine Tools, Metal-Forming CNC Machine Tools
Movement Method
Linear Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
Economical CNC Machine Tools
Certification
GS, CE, RoHS, ISO 9001
Condition
New
Name
VTC850 high quality Conventional Single Column CNC
Max. swing diameter
900
Max. turning diameter
850
Max.travel of vertical tool post(vertica
650
X axis rapid traverse
15
Tool section size
30X40
Transport Package
Plywood Case
Specification
3860*2450*3580mm
Trademark
Luzhong Machine Tool
Origin
China
HS Code
8458911090
Production Capacity
100 Set Per Month
Packaging & Delivery
Package Size
290.00cm * 220.00cm * 330.00cm
Package Gross Weight
9000.000kg
Product Description
VTC850 high quality Conventional Single Column CNC VTL Vertical lathe machine Product DescriptionProduct Parameters
Technical specifications:
| SPECIFICATIONS | Units | VTC850 |
| Max Swing Diameter over bed | mm | 900 |
| Max Swing Diameter over cross slide | mm | 850 |
| Spindle nose | - | A2-11 |
| Spindle bearing configuration | - | thrust roller bearing |
| Spindle load | kg | 800 |
| Spindle speed range | rpm | 50-800 |
| Max.torque of spindle | NM | 885 |
| Spindle chuck diameter | mm | 630( Hydraulic) |
| Max. tool post travel (vertical) | mm | 650 |
| Max. tool post travel (horizontal) | mm | -50-500 |
| Distance between tool post and chuck surface | mm | 100-750 |
| X axis rapid traverse | mm/min | 15000 |
| Z axis rapid traverse | mm/min | 12000 |
| Cutting feed speed | mm/min | 0.1-5000 |
| X axis motor power | kw | 2.4 |
| X axis motor torque | NM | 15 |
| Z axis motor power | kw | 2.8 |
| Z axis motor torque | NM | 18 |
| Turret/tool post | - | 8Hydraulic turret |
| Tool size | mm | 30*40 |
| Main motor power | kw | 22/30 |
| Positioning accuracy | mm | ±0.008 |
| Repeat positioning accuracy | mm | ±0.005 |
| Machine weight | kg | 8800 |
| Overall dimensions | mm | 2800*2000*3200 |
Detailed Photos
Company Information
Contact Us
FAQ
1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277500 China. You are warmly welcomed to visit us.
4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
5: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
