High Speed CNC Router Stone Engraving Machine
Basic Info.
Model NO.
2513T
Function
Line Engraving
Application Material
Granite
Automation
Automatic
Control
CNC
Motor Power
High Power
Engraving Head Speed Adjustability
Wide Adjustable Range
Certification
CE
Current
AC
Application
Stela & Gravestone, Stone Industry
Customized
Customized
File Format
G-Code/Hpgl
Spindle Power
7.5kw
Spindle Speed
6000-24000rpm
Voltage
AC220V/50Hz or AC380V/50Hz
Transport Package
Plastic
Specification
3800*2300*2300mm
Trademark
Jin Zuan
Origin
Fujian China
HS Code
8464909000
Production Capacity
10m/Hour
Product Description
| Model No. | 2513T-1D | |
| Platform Dimension: | 2500*1300mm | |
| Working Size: | 2400*1250mm for 1 piece | |
| Machine Body: | Thickened Steel (10mm) | |
| Working Table: | Aluminum T-Slot Table with PVC Plate | |
| Linear Guide Rail: | Y Axis PMI-25 (Two Guide Rails); X Z Axis PMI-30 | |
| Transmission: | X Y Axis Helical Rack; Z Axis Ball Screw with A Brake | |
| Feed Height: | ≤400mm | |
| Air Speed: | 20m/min | |
| Processing Speed: | 20m/min | |
| Spindle Power: | 7.5kw Water Cooling Spindle (Frequency Conversion) | |
| Spindle Speed: | 6000-24000rmp/min | |
| Drive: | Full Servo Drive | |
| Motor: | Full Servo Motor | |
| Reducer: | JZ8098 | |
| Lubrication: | Automatic Lubrication | |
| Coolant System: | Industrial Coolant System | |
| Water Tank: | Stainless Steel | |
| Operating Voltage: | AC220V/50HZ or AC380V/50HZ | |
| Engraving Tool: | Φ6/8/10/12/14/16mm | |
| File Format: | G code/HPGL | |
| Positioning Accuracy: | ±0.02mm | |
| Repeatability: | ±0.01mm | |
| Control System: | NC Studio | |
| Machine Dimension: | 3800*2300*2300mm | |
| Weight: | 2200kg |
Company Profile
Certifications
Exhibition
Packaging & Shipping
FAQ
1.What will the payment process be?
TT : 30% as deposit, 70% before shipping.
2.How many days will take shipping?
About 30 days for production time.
Shipping date from Xiamen port to your port need to be check.
3.Who will provide the technical support to installing the device?
1).Our engineer could train you for install and software using and design in our factory for free. One week is enough. Our factory
is at Shuitou town, Fujian province.
The biggest stone manufacture area in China. Maybe also the biggest importer &
exporter of marble all over the world.
2).Our engineer could service you 24 hours online by skype, whatsapp, wechat,
facebook message or by cellphone.
3).English manual for machine using and maintaining can be sent.
4).Video for installation and machine using and maintaining can be sent.
