CE EPA Hydraulic Buckets Compact Machinery Small Household Mini Crawler Micro Diggers Excavator for Sale

Product Description

Product Description

Bucket Capacity	0.025m3	Engine	KOOP 192F Diesel Engine (Euro 5)
Chassis Width	1100mm	Engine Power	7.0kw
Track Length	1300mm	EPA Engine Optional	Briggs&Stratton gasoline /13.5hp
Gradeability	40o	Max.Digging Height	2550mm
Chassis Ground Clearance	385mm	Max.Dumping Height	1710mm
Track Width	180mm	Max.Digging Depth	1740mm
Volume of fuel tank	3.5L	Max.Digging Radius	3100mm
Overall Dimension	2200*1100*2200mm	Turning Radius	1635mm
Transport Length	2400mm	Bucket excavating force	11KN
Excavator Height	2200mm	Operating Weight	1100kg
Hydraulic flow	40L/Min	Configuration	Valve:Beifang Brand
Hydraulic tank capacity	16L		Pump:KJun Brand
Working pressure	16Mpa		Piston pump
			Eaton Walking Motor

Product Details

1.
Piston pump loadsensitive, soft andpowerful action,low engine temperature, energy andfuel saving.
2.
Double row beadslewing support.High speed, high efficiency, more flexibleand more stable
3.
Double-rotary motor,double rotary support force is large,long life, play abuffer role, soft,comfortable andstable movement
4.
The track length of 41 sections increases the ground contact area and makeswalking more stable.Tailless swing, flexible and convenient
5.
American Eaton walking motor self-braking integrated motor with high efficiency and stable operation
6.
Hammer cut-offvalve,durable and wear-resistant cast steel material,good mechanical perfor-mance,prevent oil dripping and leakage
Company Profile

Product Description

Packaging & Shipping

FAQ
1: Are you factory or trading company?
A: We are factory focus in producing small size excavators.
1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, Western Union (can be) could accepted
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO.
3: What about the delivery time?
A: 7-20 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occurs first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs .
