Stainless Steel Marine Anchor Chain, Roller Chain
| US$399.00-699.00 | 100 Meters (MOQ) |
Basic Info.
Model NO.
AC-1
Design
Anchor Chain
Weight (Kg)
200kg-2t
Structure
Welded Chain
Function
Conveyor,Drag,Connected for Ship
Surface Treatment
Polished/Blackened/Galvanized
Diameter
12.5-200mm or as Per Your Request
Type
Stud/Studless Link Anchor Chain
Transport Package
Ton Bag
Specification
U1 U2 U3 marine anchor chain
Trademark
OEM
Origin
China
HS Code
7315810000
Production Capacity
500000/Year
Product Description
Stainless Steel Marine Anchor Chain, Roller ChainMaterial: Steel bar :CM390,CM490,CM690
1, Variety: Grade1, grade 2,grade 3 stud link anchor chain; studless anchor chain; buoy chain,D-type anchor shackle; Hatch-cover chain,lifting chain,kiln chain and others; DIN Standard chain; Special chain as per your requirments and their accessories.
2,Relevant Certificates: ABS, BV, CCS, DNV, KR, LR, GL, NK and RINA etc.
3.Advantage of Stud link chain:
Originally studs were added to the chain to stiffen the links preventing them from severely deforming when overloaded. They have the added advantage in that they prevent the chain from knotting up when twisted, thus avoiding problems when chain is retrieved with a windlass.
| Products | Common chains | Accessory |
| Details | All kinds of grades of marine stud and studless flash welded chains with diameter from 2mm to 122mm | All specification of Kenter shackles, Joint shackles, Anchor shackles, Swivels, Buoy shackles and Swivel shackles |
| Surface Treatments | Zinc Plated(Galvanized), Painting, Polish, Black | ||
| Material | Stainless steel 304 or 316, 20Mn2, 20MnSi ,Alloy | ||
| Standard | EUROPEAN TYPE,JIS TYPE, US. TYPE, DIN TYPE | ||
| Size | All kinds of type or according to customer's design | ||
| Heat treated | drop forged, tempered and quenched | ||
Factory workshop:
Package:
| GRADE U1,U2,U3 BLACK COATED STUD LINK ANCHOR CHAIN | |||||||
| Dia. | Proof load(KN) | Breaking load(KN) | Weight | ||||
| MM | AM1 | AM2 | AM3 | AM1 | AM2 | AM3 | kg/27.5m |
| 17.5 | 89 | 127 | 179 | 127 | 179 | 256 | 194 |
| 19 | 105 | 150 | 211 | 150 | 211 | 301 | 236 |
| 20.5 | 123 | 175 | 244 | 175 | 244 | 349 | 269 |
| 22 | 140 | 200 | 280 | 200 | 280 | 401 | 322 |
| 24 | 167 | 237 | 332 | 237 | 332 | 476 | 370 |
| 26 | 194 | 278 | 389 | 278 | 389 | 556 | 431 |
| 28 | 225 | 321 | 449 | 321 | 449 | 642 | 496 |
| 30 | 257 | 368 | 514 | 368 | 514 | 735 | 564 |
| 32 | 291 | 417 | 583 | 417 | 583 | 833 | 635 |
| 34 | 328 | 468 | 655 | 468 | 655 | 937 | 712 |
| 36 | 366 | 523 | 732 | 523 | 732 | 1050 | 800 |
| 38 | 406 | 581 | 812 | 581 | 812 | 1160 | 887 |
| 40 | 448 | 640 | 896 | 640 | 896 | 1280 | 1032 |
| 42 | 492 | 703 | 981 | 703 | 981 | 1400 | 1084 |
| 44 | 538 | 769 | 1080 | 769 | 1080 | 1540 | 1197 |
| 46 | 585 | 837 | 1170 | 837 | 1170 | 1680 | 1310 |
| 48 | 635 | 908 | 1270 | 908 | 1270 | 1810 | 1438 |
| 50 | 686 | 981 | 1370 | 981 | 1370 | 1960 | 1546 |
| 52 | 739 | 1060 | 1480 | 1060 | 1480 | 2110 | 1661 |
| 54 | 794 | 1140 | 1590 | 1140 | 1590 | 2270 | 1791 |
| 56 | 851 | 1220 | 1710 | 1220 | 1710 | 2430 | 1926 |
| 58 | 909 | 1290 | 1810 | 1290 | 1810 | 2600 | 2086 |
| 60 | 969 | 1380 | 1940 | 1380 | 1940 | 2770 | 2249 |
| 62 | 1030 | 1470 | 2060 | 1470 | 2060 | 2940 | 2361 |
| 64 | 1100 | 1560 | 2190 | 1560 | 2190 | 3130 | 2516 |
| 66 | 1160 | 1660 | 2310 | 1660 | 2310 | 3300 | 2676 |
| 68 | 1230 | 1750 | 2450 | 1750 | 2450 | 3500 | 2885 |
| 70 | 1290 | 1840 | 2580 | 1840 | 2580 | 3690 | 3010 |
| 73 | 1390 | 1990 | 2790 | 1990 | 2790 | 3990 | 3274 |
| 76 | 1500 | 2150 | 3010 | 2150 | 3010 | 4300 | 3548 |
| 78 | 1580 | 2260 | 3160 | 2260 | 3160 | 4500 | 3737 |
| 81 | 1690 | 2410 | 3380 | 2410 | 3380 | 4820 | 4030 |
| 84 | 1800 | 2580 | 3610 | 2580 | 3610 | 5160 | 4334 |
| 87 | 1920 | 2750 | 3850 | 2750 | 3850 | 5500 | 4650 |
| 90 | 2050 | 2920 | 4090 | 2920 | 4090 | 5840 | 4976 |
| 92 | 2130 | 3040 | 4260 | 3040 | 4260 | 6080 | 5199 |
| 95 | 2260 | 3230 | 4510 | 3230 | 4510 | 6440 | 5544 |
| 97 | 2340 | 3340 | 4680 | 3340 | 4680 | 6690 | 5780 |
| 100 | 2470 | 3530 | 4940 | 3530 | 4940 | 7060 | 6143 |
| 102 | 2560 | 3660 | 5120 | 3660 | 5120 | 7320 | 6398 |
| 105 | 2700 | 3850 | 5390 | 3850 | 5390 | 7700 | 6773 |
| 107 | 2790 | 3980 | 5570 | 3980 | 5570 | 7960 | 7033 |
| 111 | 2970 | 4250 | 5940 | 4250 | 5940 | 8480 | 7569 |
| 114 | 3110 | 4440 | 6230 | 4440 | 6230 | 8890 | 7983 |
| 117 | 3260 | 4650 | 6510 | 4650 | 6510 | 9300 | 8409 |
| 120 | 3400 | 4850 | 6810 | 4850 | 6810 | 9720 | 8863 |
| 122 | 3500 | 5000 | 7000 | 5000 | 7000 | 9990 | 9143 |
| 124 | 3600 | 5140 | 7200 | 5140 | 7200 | 10280 | 9598 |
| 127 | 3750 | 5350 | 7490 | 5350 | 7490 | 10710 | 9908 |
| 130 | 3900 | 5570 | 7800 | 5570 | 7800 | 11140 | 10382 |
