CNC Fixed Beam Rail Milling Machine

Product Description

Table size W	mm	1250
table size L	mm	6000
gantry width	mm	1600
spindle nose to table centre	mm	200-1000
max.loading	t/m	4
power	kw	7.5
speed	r/min	100/150/225/335/500/685
taper		NT50
speed ratio		1:1/1:5.5
working feed	mm/min	XY AXIS :30-3000
rapid feed	mm/min	XY AXIS:5000;Y AXIS:3000

1. This machine can both plane and mill workpiece if with milling head.
2. High cost performance.

Main transmission adopts SRD or servo system,wide range of stepless speed change of table's movement satisfies the requirements of planing/milling/grinding at different speed, independent spindle feeding box enables more balanced feeding to process plane/inclined plane/T slot/combined guideway/rack,etc.
1. More stable table movement.
2.To get enough lubrication of table at any speed with independent lubrication system.
3.The adoption of heat-treatment techniques like drawing the temper off/quiver-ageing/hyperacoustic quenching on key parts as the machine body/column enables more stable accuracy and longer working life.
4.Machine body/column/beam/table are designed according to the parameters of heavy-duty machines, and the material is cast iron (≥HT250),so the machine is with better stability & accuracy retentivity.
