HOWO Fire Truck/ 10000 Liter Protein Foam Fire Fighting Truck

Product Description

howo fire truck/ 10000 liter protein foam fire fighting truck Fire Fighting Truck, Fire engine Truck, Fire rescue tank truck, which are mainly used in the city or community
in case the accidental fire. Currently the fire truck has three main design. water fire truck, foam fire truck,
powder fire fighting truck.
Our company produce this three kinds of fire truck, with different brand.
Water tank fire engine truck form 3000~18000 liters.
Foam tank fire fighting truck from 3000~18000 liters
Powder tank fire rescue tank truck from 3000~18000 liters.
Or the model with three kind, water,foam,powder.

Item		Unit		Description
Model				Howo brand Fire Truck
Dimension		mm		8780*2500*3460
Tank Dimension		m3		Water Tank			Foam Tank
				8~10
		Material		Carbon Steel			Stainless steel
Curb Weight		kg		11350
Wheel Base		mm		4600
F/R track base		mm		2022 / 1830
F/R Axled-Load		Kg		7300 / 13000
Approach/Departure angle		.		16 / 10
Traction system		4*2, Or 4*4		Tire Specification/Number			12.00-20 / 6+1 Units
Max speed		100 km/h		Number of axles/ability			2
Engine model		WD615.92		Emission/kw			9726 ml/196 kw, 263 Hp
		Diesel, 6 Cylinder , direct-line, turbocharge and Water Cooling
Engine Manufacturer		Sino Truck Engine Power Group
Steering		Power		Transmission			9F&1R
Cab passenger		6~7		Electric System			24V
Dirve system		Left hand Or Right hand driven.
Fire Cannon Specification on the top fo fire truck
Fire Cannon model		PS 50, water		Working Range			Water >65 m
		PP 24, Multi					Foam >60 m
Working angle		- 30 ~ 80		Operation			Mannual
working pressure		1~1.2 Mpa
Flowing Speed		50 L / s
Fire Pump Specification
Fire Pump model		CB 10 / 60
Flowing Speed		60L/s		Pressure
Flowing Speed		42L/s		Pressure			1<P
Water input Port		DN 125mm x 1		Water suction pipe			8 m, one Unit
Liquid Output Port		DN 80mm x 2 , with ball valve control
Liquid Output Port		DN 65mm x 2, with ball valve control
Outside water input port
Liqid input Port		DN 65 x 2 Unit, at two side of fire truck
Foam tank specifiation
2000 liter, pipe and valve are all stainless steel material
Installing
Long beem alarm light, light detector x2~12V60W, 5 Unit Window type warehous, Rear climp ladder
