UL94 Horizontal Vertical Flammability Tester ASTM D5207

Product Description

Product Description
Product Description
AT840 UL94 Horizontal and Vertical Flammability Tester is used to evaluate compliance the ignition resistance properties of component parts and materials of apparatus and instruments, and suitable for determining the flammability properties such as flammable properties, burning rate, flame spread speed, burning intensity and flammability resistance of products.
Standard

Horizontal flammability test	UL HB, IEC 60695-11-10, IEC60707, ISO 1210, GB/T 2408
50W vertical flammability test	UL94 V0, V1, V2, IEC60695-11-10, ISO 1210, GB/T 2408
500W vertical flammability test	5VA, 5VB, IEC 60695-11-20, ISO 9770, GB/T 5169.17
Thin flexible material vertical flammability test	VTM-0, VTM-1, VTM-2, ISO 9773
Cellular plastic material horizontal flammability test	HF-1, HF-2, HBF, ISO 9772, GB/T 8332

Specification

Model	AT840
Burner brand	Humboldt, USA
Burner diameter	Φ0.9±0.03mm
Burner angle	0°, 20°, 45° adjustable
Flame height	20~200mm
Pressure reducer brand	MARSH BELLOFRAM, USA
Chamber volume	0.75m3
Instrument dimensions	800mm×920mm×1270mm
Power supply	220V, 50Hz

Details & Features
★Volume of test chamber larger than 0.75m3; ★Large observation window, easy to observe burning state;
★Humanization design, easy to adjust specimen and burner;
★0°, 20°, 45°angle of burner is adjustable;
★Bunsen burner igniting source, as per ASTM D5025;
★Record test time by timer on control panel;
★Adjust burning gas flow by rotor flow meter;
★High accuracy pressure regulating valve to provide needed gas pressure;
★Wingtip burner, as per ASTM D4986;
★Equipped with gas suction device to remove waste gas;
★Burner calibration system, as per ASTM D5207
Our Company
History
Since 1982 with more than 20 years’ experience
Warranty
Two Year Warranty for whole product
Training
Video and user manual for training
Onsite service
Installation and training service is available
Testing service
Free sample testing before order is available
Lead time
15 working days lead time for most product
Packing & Delivery

Packaging
Packaging Details	1. The equipment is covered with film is protect it from water vapour during the trip.  2. The box is filled with foam to protect the equipment from impact.  3. Exported wooden box made from plywood, don't need fumigated.

Payment

Payment Term	T/T	EXW	30% T/T in advance, paid the balance before shipment
					FOB
				CFR(C&F)	30% T/T in advance, paid the balance against copy of B/L
				CIF
		L/C	L/C amount above 50,000 usd, we can accept L/C at sight
		West Union	Amount lower than 5000usd
		West Union
Delivery Time	7~10days after receiving payment for one container
