Viqee ODM/OEM Advertisement Portable Ak1-PRO Mini All-in-One Pocket Palm Computer PC
| US$105.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
AK1-Pro
OS
Windows11/Ubuntu, etc.
Memory Capacity
8g/16g RAM
Applications
Palm Computer
CPU Type
Intel
Internet Connection
WI-FI
Classification
2.9GHz Frequency
Color
Black/Customized
Shell Material
Plastic
Net Weight
386g
Gross Weight
759g
Installation Method
Embedded/Wall-Mounted/Desktop
Ready Stock
Yes
Us/EU Warehouse
Yes
Transport Package
Standard Packing
Specification
128mm*128mm*51.5mm
Trademark
VIQEE / Customized
Origin
China
HS Code
8471499900
Production Capacity
3000PCS/Month
Packaging & Delivery
Package Size
20.00cm * 20.00cm * 15.00cm
Package Gross Weight
2.000kg
Product Description
Product Description VIQEE Mini PC SeriesModel AK1-Pro
Extensible configuration
Dual-screen HDMI HD output
More Application Scenarios
Rich Interface
Support OEM/ODM
Customized Color/Capacity/System/Appearance Material
Detailed Photos
Product Parameters
| Product Appearance | |||
| Type | Spec. | Standard Configuration | Optional |
| Product | Product Type | MINI PC | |
| Special | 1. With vertical stand, can be placed flat, can be placed upright 2. Personalized setting LCD 3. Magnetic cover, easy to DIY | ||
| Dimension | 136*124*41.9mm | ||
| Case Material | Plastic | ||
| Weight | |||
| System Hardware Configuration | |||
| Type | Spec. | Standard Configuration | Optional |
| CPU | Model | Alder lake N95 | |
| manufacturing process | / | ||
| core | 4 cores and 4 threads | ||
| cache | 6 MB | ||
| base speed | 1.7Ghz | ||
| Maximum speed | 3.4GHz | ||
| power wastage | 15W | ||
| GPU | Model | Intel® UHD Graphics | |
| core | / | ||
| speed | 1.20 GHz | ||
| resolution | / | ||
| Memory | Model | SODIMM DDR4 *1 | |
| speed | 3200MHz | ||
| Capacity | Up to 16GB | ||
| Storage | SSD Capacity | SSD(Up to 2TB) | |
| SSD Type | M.2 x2 (one SATA only, default shipping; one PCIE/SATA adaptive) | ||
| 2.5 inch HHD | NO | ||
| TF card | NO | ||
| RTC | BIOS Support | Real-time clock, timed power-up | |
| power-on | BIOS Support | Supports automatic power-on after power-on | |
| diskless network | BIOS Support | Support uefi diskless boot | |
| TPM | CPU Integrated TPM | Supports TPM 2.0 | |
| multi-screen | video output | Supports 2 HDMI | |
| LCD | Personalized Display | 1.9" TFT LCD 170*320 | |
| LED | status indicator | RGB Ambient Lighting | |
| Internet Connection | |||
| Type | Spec. | on board | Optional |
| WIFI | Model | M.2 E_Key | |
| protocols | IEEE 802.11 a, b/g, n, ac,ax (wifi 6) | ||
| Bluetooth | Model | USB2.0 | |
| protocols | Support Bluetooth 5.2 | ||
| 3G | built-in | NO | |
| 4G | built-in | NO | |
| Ethernet | LAN1 | 10M/100M/1000M Adaptive | |
| interface | |||
| Type | Spec. | Standard Configuration | Optional |
| USB | USB2.0 | USB2.0 Type-A x2 480mbps | |
| USB | USB3.0 | USB3.0 Type-A*2 5Gbps | |
| TF | Expanded External Storage | NO | |
| HDMI | video output | HDMI 2.0(Max 4K 60HZ)*2 | |
| DP | 4K audio and video output | NO | |
| VGA | video output | NO | |
| RJ45 | Gigabit Ethernet | RJ45 1000Mbps *2 | |
| Type C | data transmission | NO | |
| POWER | Power Button | x1 | |
| DC IN | Power Supply Input | 5.5/2.1mm DC Jack x1 | |
| Audio-in/out | Audio-in/out | 3.5mm Phone Jack x1 (2-in-1 connector) | |
| Antenna1 | FPC Antenna | WiFi 2.4+5G+BT x1 | |
| Antenna2 | FPC Antenna | WIFI 6.0 | |
| SIM | micro SIM | not support | |
| Software Configuration | |||
| Type | Spec. | Standard Configuration | Optional |
| OS | Version | Win11/Linux | |
| Environment | |||
| Type | Spec. | Standard Configuration | Optional |
| Environment | Working Temperature | 0~40ºC | |
| Memory Temperature | -20~60ºC | ||
| Humidity | 90% @ 40 °C (no condensation) | ||
| Accessory | |||
| Type | Spec. | Standard Configuration | Optional |
| Power Supply | Desktop/Plug-in | Input 100~240V 50/60Hz Output 12V/3 DC Header 5.5*2.1mm | |
| IR Remote Control | not support | ||
| VESA Mount | not support | ||
