New Design Crusher for Plastic Recycling for Sale

Product Description

New Design Crusher For Plastic Recycling For sale
Plastic Crusher brief introduction:
The DGH Heavu Duty Granulating Crusher has a centrally hinged two-piece cutting chamber with a robust welded steel construction, with the upper and lower sections of the housing meeting horizontally. Reversible stator knives with double cutting edges are fitted as single elements to the lower section of the housing, allowing multiple re-sharpening and adjustment of the stator knives.There is a hinged screen cradle and hinged door for easy screen access.
The rotor is a heavy duty paddle type design with knife cover plates to protect the blades when processing abrasive applications.The knife mounting bolts are screwed into the mounting plates as opposed to the rator.All knives are manufactured from chrome nickel tool steel as standard, but when processing applications that are particularly abrasive the DGH granulators can be fitted with a speciallly designed wear ressistant rotor utilizing wear resistant steel parts and hardox facing.
The v-cut cutting geometry offers distinct advantages over other rotor designs, including higher throughput with reduced power consumption,better quality cut, and lower noise levels. Specially designed knife setting jig means that the knives can be adjusted from outside the machine, significantly reducing the downtime required to change/set knives.
The base frame has a solid welded construction with anti-vibrationn rubber feet to reduce vibration and noise. The drive motor is mounted on tension rails to allow easy adjustment of the V-belt tension. Integrated suction trough for material discharge.Specially designed hopper with 3 sets of curtains to prevent material flybacks.
Integrated rundown safety device precents access to the rotor until is has come to a complete stop.A safety device prevents access to the rotor until it has come to a complete stop. A safety switch prevents machine startup when the front panel is open and the machine feature emergency stop buttons on the machine body and control panel.
Pictures of Plastic granulating Equipment:
Specification for Plastic Crusher :

Item		Unit	DGH350/500	DGH500/600	DGH600/800	DGH500/1000	DGH700/1000	DGH800/1200	DGH800/1600	DGH800/2000
Rotor Diameter		mm	350	500	600	500	700	800	800	800
Rotor Width		mm	500	600	800	1000	1000	1200	1600	2000
Rotor Knives		pcs	3*2/5*2	3*2/5*2	5*2/7*2	3*2/5*2	5*2/7*2/9*2	7*2/9*2	7*4/9*4	7*4/9*4
Stator Knives		row	2/3	2/3	2/3	2/3	2/3	2/3	2/3	2/3
Cutting Chamber Dimensions		mm	516*460	636*590	790*695	985*590	985*800	1150*915	1570*915	1960*915
Motor Power		kw	15-22	37-55	55-90	55-90	75-110	110-160	132-200	160-200*2
Dimensions	A	mm	1800	2080	2300	2230	2800	3100	3140	2740
	B	mm	1600	1850	2100	2000	2500	2800	2800	2600
	C	mm	1250	1530	1850	1950	2060	2360	2800	3460
	D	mm	770	940	1120	1350	1290	1530	1960	2250
	E	mm	2500	2620	3000	2860	3420	3820	4250	4775

Layout for Plastic Crusher:

Key Features of crusher/granulating equipment	Alternertive Options
*Deflector wedge *V-cut technology *Heavy duty bearings *Oversized external bearing housings *Knives are externally adjustable *Robust welded steel construction *Wide choice of rotor variations *Electrical hydraulic control to open housing *Electrical hydraulic control to open screen cradle *Amp meter control *Replaceable wear plates	*Extra flywheel *Double infeed hopper *Roller feeder *Mounted screw feeder in hopper *Winding protection *Metal detector *Metal separator *Bespoke colour scheme *Increased motor drive

Certificates:
Production for Plastic Crusher :
Packing and Shipping
1. Several layers of plastic wrapping film and cardboard to protect plastic crusher from dust and moisture.
2. Plastic packing strap belt to fasten wrapping film and machines, also to fix machines in containers.
3. Wooden case is used as the outside package and spare parts when choosing by LCL, air or international express.
4. Excellent logistic team to guarantee the single shaft crusher to be safely shipped to customers appointed location.
5. If you have any other request for the packaging or loading, we will do our best to meet your demands.
Company Introduction
Since its foundation DGM Recycling Systems have been at the forefront of innovation and technology in the development of cost effective and reliable recycling solutions. As a wholly owned subsidiary of Miracle Automation Engineering Group, a pioneer in automation systems for the automotive and material handling industries, DGM continues to strive for excellence in the field of size reduction and recycling. Utilizing core German design and technology, we have expanded our scope of application to include plastics,timber,rubber,biomass and many other industries where size reduction and materials processing are critical. Our dedication to product development and attention to individual customer needs means we are well equipped to offerr successful business solutions and tailor-made processing plants to our customers.
FAQ
Q1: Are you a trading company or a factory ?
DGM is a factory with 10 years experience in tire and plastic machinery manufacturing, and 20 years experience in technology.
Q2: Will you provide pre-sale services?
DGM consists of experienced specialists, we will offer a suitable solution according client's requirement in time.
Q3: Is your after-sales service excellent?
At DGM we have a highly trained team of service personnel to handle all manner of customer service enquiries. Whether it is replacement parts, technical assistance, or just general operation advice we offer our customers genuine 24/7 support and after sale service. We have an international network which ensures wherever you are in the world you receive localized high level support.
Our technical team has decades of experience in the field of size reduction, washing line and tire recycling and we are on hand to offer assistance in installation, commissioning, staff training and general technical assistance.
Q4: Where is your factory?
Address: No.1.Fengqi Road, Huishan District , Wuxi City, Jiangsu Province, China
Q5: What is your contact informatoin?
Fax: +86 510 8357 0210
Telephone: +86 510 83450018-8015
Q6: Could we visit your factory and test the machine?
We warmly welcome you to visit our factory anytime,and we are very glad to test our machine with your raw material.
DGM---Qualified supplier to offer you high quality plastic crusher.
