CNC Machine Lathe Precision Lathe Machine Vmc Jt-855V
| US$28,000.00-35,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
JT-855V
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools, CNC Non-Conventional Machine Tools, Metal-Forming CNC Machine Tools
Movement Method
Point to Point Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
High-End CNC Machine Tools
Condition
New
Precision
High Precision
Net Weight
5500kg
Tool Libranes
21 Arm Type Tool Libranes
Standard System
Mitsubishi M80
Transport Package
Seaworthy Packing
Specification
2400*2350*2750mm
Trademark
JT
Origin
China
HS Code
8458110000
Production Capacity
1500sets/Year
Product Description
Product Parameters
| ITEM | UNIT | JT-855V | |
| Workbench | Workbench size | mm | 1000*550 |
| Worktable load-bearing capacity | kg | 600 | |
| T-slot width (width x spacing x number of slots) | mm | 18*100*5 | |
| Trip | X-axis travel | mm | 800 |
| Y-axis travel | mm | 550 | |
| Z-axis travel | mm | 550 | |
| Distance from spindle end face to workbench | mm | 120-670 | |
| Distance from spindle center to Z-axis rail surface | mm | 590 | |
| Principal axis | Speed range | rpm | 12000 |
| Main spindle power (continuous/30 minute rated) | kw | 11/15 | |
| Slope of spindle inner hole | BT40 | ||
| Transmission mode | |||
| Feed | X-axis rapid displacement | m/min | 30 |
| Y-axis rapid displacement | m/min | 30 | |
| Z-axis rapid displacement | m/min | 30 | |
| Feed rate | mm/min | 12000 | |
| Automatic tool change system | Tool magazine capacity | set | 24 |
| Maximum tool outer diameter (when fully loade | mm | 65 | |
| Expanding the diameter of the hollow blade | mm | 100 | |
| Maximum tool length | mm | 160 | |
| Maximum tool weight | kg | 2 | |
| Tool change time (knife to knife) | sec | 2 | |
| Precision VD13441 (JISB6338) | Positioning accuracy | mm | P0.01(±0.004/300) |
| Repetitive accuracy | mm | Ps0.008(±0.003) | |
| Other | Electricity dernad | Kva | 15 |
| Barometric pressure demand (minimum) | kg/cm² | 5.5 | |
| Cuting fluid capacity | liter | 250 | |
| Machine footprint | mm(approximately) | 2400*2350 | |
| Machine height | mm(approximately) | 2750 | |
| Machine weight | kg(approximately) | 5200 | |
