LK Potenza-II 850 Ton Plastic Injection Molding Machine

Product Description

Brief Introduction
LK group specializes in the design manufacture and sales of die casting machines, high precision injection molding machines, CNC machine centers, and industrial integrated control systems. Our market share of die casting machines is over 60%, the injection molding machine ranks among the top 3 in China.We have 12 companies worldwide, 10 in domestic China, 1 in Taiwan, and 1 acquired company in Italy. Our injection molding machine centers are Zhongshan in Guangdong and Ningbo in Zhejiang.There are over 60 sales and service centers in the world, and our high-quality after-sales service and 24-hour prompt response system provide customs all-around fully coverage customers service.
Key features
1.German gear pump with permanent magnet servo motor
2.Professional controller system
3.Study toggle clamp system with advanced FEA engineering design
4.Excellent kinetic motion characteristic
Use of application
Power Tool, Personal Care, Toys, Electrical Appliances, Body Parts, Steering Wheels, Small Packaging, Daily product
Technical Parameter List

	ITEM	UNIT	PT850
Injection Unit	Shot Weight	g	2748	3393	4105	4886
	Screw Diameter	mm	90	100	110	120
	Injection Volume	cm3	3020	3729	4511	5369
	Injection Pressure	MPa	218	176	146	122
	Screw L/D Ratio	L/D	24.4	22	20	18.3
	Injection Rate	cm3/s	670	827	1000	1190
	Plasticizing Capacity	Kg/hr	284	346	410	478
	Screw Speed	r/min	110
	Hopper Capacity	L	150
Clamping Part	Locking Force	kN	8500
	Die Height(Min.-Max.)	mm	400-1100
	Opening Stroke	mm	1100
	Space Between Tie Bars	mm	1080×1020
	Ejector Stroke	mm	300
	Ejector Force	kN	270
Other	Pump Motor Power	kW	44×2
	Max Working Pressure	MPa	17.5
	Oil Tank Capacity	L	1000
	Heating Capacity	kW	62.3
	Machine Dimensions (L×W×H)	mm	11500×2480×2500
