Nano Silver Chrome Effect Epoxy Powder Coating Paint to Replace Electroplating

Product Description

PRODUCT DESCRIPTION
Powder coatings are mixed with a certain proportion of the resin, fillers, curing agents and other additives, and then prepared by hot extrusion, crushed and sieved. The products are stable at room temperature storage, and then baking heat melted and solidified to form a smooth and bright permanent coating to achieve the purpose of decoration and anti-corrosion.
WONDER Powder Coatings are suitable for metal/iron/aluminum surface of each indoor or outdoor product such as furniture, electrical appliance, industrial equipment, sports equipment, kitchenware, shop tool rack, lamps and lanterns and construction machinery etc.
Thousands of colors (RAL, Pantone, customized colors)Nano dry-plating colors (chrome, shiny & mirror effect)Metallic colors (gold, silver to replace oil paint)Special texture (wrinkle, sand, hammer etc) PRODUCT PARAMETERS

Product Details
Type	Nano Silver Chrome Effect Epoxy Powder Coating Paint to Replace Electroplating
Color	metallic
Surface Finish	smooth
Gloss level	500-560%
Particle Size	Average 32-42μm
Specific Gravity	1.2-1.7g per cubic meter
Coverage	7-8 square meters per Kg at 60-80 μm film thickness
film thickness	60-80um
Application Recommendation
Application Voltage	60-90 KV
Gun to Component Distance	15-30CM
Curing Temperature	180-200ºC,10 min-15 min
Powder coated Film Mechanical Properties
Adhesion	Cross-cut(2mm),no loss of adhesion
Impact Resistance	Direct impact 50kg/cm
Pencil Hardness	1H-2H
Cupping Test	6mm Mandrel
Bending Test	5mm
Powder Coated Film Chemical Resistance
Salt Spray Test	5% NaCl Solution for 500 hours - No change
Acid Resistance	5% HCL for 48 hours dip test - No change
Alkali Resistance	5% NaOH for 48 hours dip test - No change
Storage Stability
Store in ventilated, dry, clean room, temperature < 25ºC
Relative humidity 50-65%
Away from direct sunlight, fire, heat
For best performance, use within 6 month

POWDER TEST
QUALITY CONTROLRaw materials: Internal and External Test before taking delivery of every raw material to make sure they are all qualified without any heavy metal substance.During Production: Every production has a spray booth, spot check the powder every 1-2 hours to guarantee stable quality.Finished Product: The QC keeps 100g from each batch of mass production, so that we could act quickly when we receive feedbacks from our clients and solve the problems efficiently.Traceability: Standard Panels for every batch of production for 5 years. Kept sample powder for 24 months.
TECHNICAL SUPPORT
We have professional after-sales service for every customer.
Before: Advice on coating ling setup, integrated solution on coating.
During: Processional production tracking. Punctual delivery.
After: Quality tracking system. Regular follow-up.PRODUCTION PROCESS
PACKAGE & DELIVERY
CERTIFICATION
WONDER Powder Coatings can pass ROHS, EN71 standards. We can also provide powders with FDA, REACH and other certifications as customers require.
WONDER FACTORIES
1. Production workshop set up in 1989, leading powder coating supplier with rich experience in China.
2. 4 Factories in total. Three are Powder Coating Production Bases; one is Nano-Dryplating Spraying Base.
16 Production Lines.
5 Bonding Lines.
9 Sample Lines.
Annual Capacity reaches 10,000 Tons.
3. Nano-Dryplating Silver Chrome Effect Powder Coating is identified as Guangdong High-Tech Product.
4. Export to oversea countries: Sweden, Turkey, Russia, US, Central America, Peru, Costa Rica, Pakistan, Kazakhstan, UAE, Vietnam, Thailand, Malaysia etc.
FAQ
Q: Can I have a sample order for Powder Coating?
A : Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q: What about the lead time?
A: Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than 10 tons, needs about 20 week days.
Q: Do you have any MOQ limit for powder coating order?
A: Low MOQ, 1kg for sample checking is available
Q: How to proceed an order for powder coating?
A : Firstly let us know your requirements or application(For indoor or outdoor use). Secondly We quote according to your requirements or our suggestions. Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production.
Q: Is it OK to print my logo on package?
A : Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
