Ztcl Telesopic Articulated Boom Lift Man Lift Aerial Work Platform Genie Haulotte Zoomlion Electric Diese

Product Description

Product Description
Self-propelled boom lift,It is the highest-efficiency straight boom aerial work platform. It is provided with the double-operating-radius curve, the machine has the industry-leading operating altitude(8-22m)/radius(5.3m to 11.7m) and carrying capacity. The device is powered by a high-efficiency battery pack and can also be charged through a standard power socket.
The whole machine has simple structure, reliable safety and more convenient operation.You can operate it from the chassis control or platform control. And it can be used for two workers to work on the platform at the same time. This type of machine may satisfy the diversified demands of different industrial users engaged in building construction, bridge and equipment maintenance, shipbuilding, petrochemical engineering, lease etc. Product Parameters

Model	ZTGTBZ8	ZTGTBZ10	ZTGTBZ12	ZTGTBZ14	ZTGTBZ16	ZTGTBZ18	GTBZ20
Lift height(m)	8.5	10	12	14	16	18	20
Working height(m)	10.5	12	14	16	18	20	22
Loading capacity(kg)	200	200	200	200	230	230	230
Platform size(mm)	1530*780	1530*780	1530*780	1530*780	1880*780	1880*780	1880*780
Dimension(mm)	5520*1670*2090	5760*1670*2090	6400*1780*2190	7020*1780*2190	7380*2090*2200	8400*2280*2600	8860*2280*2600
Weight(kg)	5100	5200	5900	6500	7400	10300	11500
Power source:	Diesel engine power / Battery power

Detailed Photos
Product show

Our Advantages
1.Turntable rotates 360 hydraulic platform rotates horizontally, forearm swings up and down.
2.Storage height 2m easy to pass through doorways.
3.Compact rotation radius and with allowing work in crowded venues.
4.Full scale control of platform.
5.Platform loading limitations, which improves security.
6.Two people with tools working simultaneously.
7.Single Handle Smooth Proportion Controls All Action.
8.Two-wheel or four-wheel drive (choice of solid tyres or crawler).
9.Fast lifting speed zero swing of tail, suitable for working in limited space. FAQ
Q1. What about the delivery time?
Answer: It usually takes about 10 working days after we receive the deposit.
Q2. What kind of payment do you support?
Answer: T/T, L/C, West Union, T/T is usually.
Q3. How to proceed an order for the lift?
Answer: Firstly, tell us your requirements, if you can send a photo where you will use the lift, it will be better.
Secondly, we send you our suggestions and quote according to the practical.
Q4. How to transfer the lift machine?
Answer: It is usually shipped by sea. Plywood package and LCL in a 40' container.
Q5. Is it OK to print my LOGO on the lift?
Answer: Yes. Please inform us formally before our production and send us your high pixel LOGO.
Q6. How can I get the after-sales service?
Answer: Contact with us if you have any question or need professional support. We will try to solve your problem in 24 hours, and arrange the delivery of spare parts in 48 hours.
