Jy180V Household Micro Lathe Mini Lathe Variable Speed Instrument Teaching Lathe
| US$1,200.00-2,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
JY180V
Type
Horizontal Lathe
Processing Accessory
Metal
Guide Rail
Horizontal Guide Rail
Tool Holder
4 Way Tool Post
Power Source
Electric
Controlling Mode
Artificial
Automatic Grade
Manual
Setting Mode
Floor-type
Precision
High Precision
Certification
CE, RoHS, ISO 9001
Condition
New
Max.Swing Over Bed
210mm
Spindle Taper
Mt3
Transport Package
Plywood Case
Specification
3200kgs
Trademark
HOYONG
Origin
Shandong, China
HS Code
84581900
Production Capacity
10 PCS/Month
Product Description
V-way bed is hardened and precision ground.
Power longitudinal feed allows threading
Spindle is supported by precision taper roller bearing
Adjustable gibs for slideways
Tailstock can be offset for turning tapers
| MODEL | WM180V |
| Max. swing over bed | 180mm |
| Distance between centers | 300mm |
| Spindle bore | 21mm |
| Taper of Spindle bore | MT3 |
| Range of Spindle speeds | 50-2500rpm |
| Taper of tailstock quill | MT2 |
| Metric threads can be cut | 0.5-3mm |
| Inch threads can be cut | 10-44TPI |
| Max travel of cross slide | 75mm |
| Bed of width | 100mm |
| Travel of Tailstock sleeve | 60mm |
| Motor power | 650W |
| GW/NW | 75/60KG |
| Package size( L*W*H ) | 780*480*420mm |
