X8130A Factory Directsale Universal Tool Milling Machine
| US$3,500.00-11,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
X8130A
Structure
Lifts
Milling Cutter Type
Vertical Milling Cutter
Milling Cutter Structure
Indexable Type
Controlling Mode
Artificial
Automatic Grade
Manual
Precision
High Precision
Certification
CE, RoHS, ISO 9001
Condition
New
Table Size
225X830mm
T Slot No./Width/Distance
5/14/60mm
Spindle Taper Bore
ISO40
Motor
2.2kw
Quill Movement
80mm
Transport Package
Plywood Case
Specification
1100kgs
Trademark
HOTON
Origin
Shandong, China
HS Code
8459590000
Production Capacity
10 PCS/Month
Product Description
UNIVERSAL TOOL MILLING MACHINE X8130A
This machine is a versatile machine of better universality,extensively used for milling flat,inclined
surfaces and slots on metal parts and is suitable for machining tolls,fixtrues and moulds as well as
machine parts of complicated shapes in instruments and meters manufacturing jplants and machinery
building works
SPECIFICATIONS:
| MODEL | X8130A |
| Horizontal working surface | 320x750mm |
| T slot no./width/distance | 5 /14mm /60mm |
| Vertical working surface | 225x830mm |
| T slot no./width/distance | 2 /14mm /126mm |
| Max. longitudinal travel( by hand/power) | 405/395mm |
| Max. vertical travel( by hand/power) | 390/380mm |
| Max. cross travel | 200mm |
| spindle taper bore | ISO40 7:24 |
| Max. swivel of vertical milling head | ±60° |
| Distance from axis of horizontal spindle to table surface (Min./Max.) | 35/425mm |
| Distance from vertical table to guideway | 188mm |
| Quill movement | 80mm |
| Number of spindle speeds | 12 |
| Range of spindle speeds | 40-1600r/min |
| Main drive motor power | 2.2kw |
| Speed of Main drive motor | 1430r/min |
| Overall dimension | 1170x1210x1600mm |
| Net weight | 1100kgs |
