Body Lotion Emulsifying Machine
| US$9,500.00-130,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
Body Lotion Emulsifying Machine
Application
Granules, Viscous Fluid
Application Area
Agricultural Chemicals, Chemical, Daily Chemical, Pharmaceutical
Certification
CE, ISO, CE, GMP, ISO
Condition
New, New
Control System
PLC Control
Cooling Method
Water Cooling
Heating Method
Electric Heating
Main Material
Stainless Steel
Mixing Capacity
50-99L
Mixing Drum Shape
Circular Groove
Speed Control
Dual Speed
Speed Range
40-49 R/min
Stirring Type
Spiral
Temperature Control
With Cooling System
Working
High Speed Mixer
Finished Dosage Form
Emulsifier
Precision
High Precision
Voltage
380V
Computerized
Computerized
Customized
Customized
Warranty
1 Year
Type
Emulsifying Machine
Item Name
Body Lotion Emulsifying Machine
Model
Ltrz-600
Volume
600
Material Consist
Inner SUS316L, Outer SUS304
Control
Micro Computer (PLC Control Available)
Operation
Button Control (Touch Screen Available)
Power
380V 50Hz Three Phase
Usage
Pharmaceutical, Cosmetics, Food, etc
Power Supply
24kw
Working Capacity
220-500L
Transport Package
Wooden Case
Specification
CE, GMP
Trademark
LTPM China
Origin
China
HS Code
8479820090
Production Capacity
600L
Product Description
Product Description The product is mainly applied in such industries as daily chemical care products, biopharmaceutical industry, food industry, paint and ink, nanometer materials, petrochemical industry, printing and dyeing auxiliaries, pulp & paper, pesticide, fertilier, plastic & rubber, electrics and electronics, fine chemical industry, etc. The emulsifying effect is more prominent for materials of high base viscosity and high solid content. Features: 1.Complex scraping board blending oar is suitable to every kind of complicated recipe and achieve optimizing effect;2. Polytetrafluroethylene scraping board cater to body of blending groove and scrape out viscosity material on boiler wall;
3.Homogenizer is installed on boiler bottom to increase motor power more thoroughly and strongly. During fewproduction, it can exert homogenizing effect fully;
4.Mightiness balance isotactic curve rotor is matched with stator with corresponding structure to realize liquid high -capability cut,rubbing,centrifugal to make sure exquisite and slick cream; boiler body and pipe surface mirror polishing 300EMSH (sanitation grade) accords with Daily Chemical and GMP regulation.
5.Homogenizing vacuum emulsifier mixer can choose frequency conversion timing homogenizer and highest rotate speed is 4500 r/min
| Manufacturer | China LTPM Group Co., LTD | ||
| PN | 200L vacuum emulsifying mixer | ||
| Capacity | Design volume: 200L, working capacity:160L | ||
| Kettle Cover | Liquid(particle)inlet, sunk material inlet, air inlet with filter, inspect light and sight glass, vacuum port, pressure meter(1 to-0.1 bar), pressure clamp | ||
| Mixing pot | Material | Inner layer: SUS316L thickness: 4mm | |
| Middle layer: SUS304 thickness: 4mm | |||
| Outside layer: SUS304 thickness:3mm | |||
| configuration | Bottom material exhaust, size: 1.5" | ||
| Temp. sensor (0-199ºC) | |||
| Electrical heating: 8kw, cooling water inlet | |||
| Stirring system | Homogenizer | 1.Material: SUS316L; standard homogenizer 2. Power: 4kw/380/50Hz; RPM: 0--2800R/Min | |
| Stirring scrap and middle stirring | Material: SUS316L,Scrap material: PTFE | ||
| 1. Stirring scrap and middle stirring use the same motor 2,Power:1.5 kw/380V/50Hz;RPM:0~86r/min(Frequency control) 3. Stirring scrap and middle stirring rotating the opposite direction | |||
| Safety: 1. During stirring, the cover can not open, 2. Cover lift can not stirring. | |||
| Vacuum system | 1. Vacuum pump: water recycle, power 1.5kw/380V/50Hz 2. With pressure sensor (during vacuum condition, hydraulic can not open) | ||
| Heating method | Jacket electrical heating | ||
| Exhaust method | Electric doom and bottom discharge or positive pressure discharge material | ||
| Pressure | Pressure in the pot during working: -0.090 Mpa; Jacket working pressure:0.2 Mpa | ||
| Control box | SUS304 , 1.2mm thickness | ||
| Dimension | 1900mm×600mm×2650~3500 mm | ||
| Shelf is SS, platform with raised platform and SS guardrail | |||
| Spare parts | One year spare parts and tools | ||
| Guarantee | One year | ||
| Using life | More than 15 years | ||
Product Details
Product Highlights
Final Product
Q: What price terms you offer?
A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based on your request.
Q: What payment terms you take?
A: TT, LC, other terms are also workable.
Q: Will you help with installation and stuff training?
A: Yes, we can send our engineers to your place to guide the installation and train your workers if you need, but the buyer should
bear our technician's round tickets, accomodation, food and subsidiary USD100/day.
Q: How can I visit your factory?
A: Our factory is located in Ruian city Zhejiang Province. Just let us know your scheduel in advance and we will arrange
everything for you!
Any other doubts about our machine, please feel easy to contact with us.
