High-Output Expanded Metal Mesh Machine for Fencing and Anti-Climb Flooring

Product Description

Efficient expanded metal mesh production equipment | High-precision, high-yield
Product Description
The steel plate mesh machine works by processing metal sheets into mesh structures through processes such as punching, stretching, or welding. The exact method depends on the type of machine and the desired characteristics of the steel mesh.
Our expanded metal machines use advanced technology to efficiently and precisely produce expanded metals of various specifications, which are widely used in construction, mining, transportation and other industries. Detailed Photos
Product advantage
1.High Efficiency: Fast and consistent production.
2.Durable Construction: Made from high-quality materials for long-lasting use.
3.Adjustable Mesh Size: Customizable mesh size according to specific needs.
4.Easy Operation: User-friendly interface and controls.
5.Low Maintenance: Simple maintenance process to ensure continuous operation.
6.Energy Saving: Designed to be energy-efficient, reducing operational costs.
Why Choose Us
1.High-Quality Output: Consistent, accurate mesh production.
2.Customizable: Flexible settings for different mesh sizes and applications.
3.Cost-Effective: Durable design reduces the need for frequent replacements.
4.Advanced Technology: Incorporates the latest machine design and control systems.
5.Reliable Support: Comprehensive customer service and after-sales support.

Model	10T	25T	40T	100T	160T	360T
Punch speed	500R/m	260R/m	110R/m	65R/m	55R/m	45R/m
LWD Max.	12mm	30mm	80mm	180mm	240mm	200mm
Thick.	0.1-1.0mm	0.2-1.5mm	0.5-2.5mm	0.5-5mm	0.5-6mm	1-10mm
Width Max.	650mm	1250mm	1500mm	2500mm	3200mm	2500mm
Feeding distance	0-6mm	0-5mm	0-10mm	0-10mm	0-10mm	0-10mm
Motor	7.5kw/1000rpm	5.5kw/1440rpm	11kw/1400rpm	22kw/1470rpm	30kw/1470rpm	55kw/1470rpm
Weight	1.5T	3.9T	6T	14T	18T	36T

The steel plate mesh machine operates by feeding steel plates into a system where automated processes cut, bend, and weld them into precise mesh patterns. The machine adjusts mesh sizes as needed, creating a strong and reliable final product.
1.Construction industry: used for wall protection, ground support, door and window protection, etc.
2.Transportation field: used for highway guardrails, railway guardrails, bridge protection nets, etc.
3.Mining industry: used for ore screening, mineral transportation, etc.
4.Industrial equipment: used for filtering, conveying, protection, etc.
5.Agriculture field: used for greenhouse nets, insect-proof nets, etc.
There are other uses, but the text is limited in space, so please contact us for details. After Sales Service
1. Installation and commissioning - technicians can be arranged to carry out installation and commissioning work locally
2. Training and operation - salesmen provide installation videos and machine manuals
3. Warranty period - 1 year free warranty, lifetime free consultation
4. Accessories supply - sufficient inventory, and vulnerable accessories can be purchased at any time
5. Maintenance service - regular inspection/lubrication maintenance/cleaning, the salesperson will inform the specific method.
FAQ
1.How to choose the appropriate specifications of expanded metal machine?
Please tell us the purpose or specification of the finished product you want to produce, and we will match you with the most suitable machines and accessories.
2.Do you provide customized services?
Of course, we provide free customization services, including color, LOGO, etc.
3.How to maintain equipment and extend its service life?
We will provide specific methods. If you have any other questions, please feel free to contact us and we will respond in time.
