Klt-X9mf-Ov5640-1b V1.2 WiFi Camera 5MP Ov5640-1b Mipi and Dvp Parallel Interface M12 Fixed Focus Camera Module
| US$20.00-22.00 | 100 Pieces (MOQ) |
Basic Info.
Model NO.
KLT-X9MF-OV5640-1B V1.2
Application
Fixed Focus
Interface Type
Mipi and Dvp Parallel
Transport Package
Anti-Static Bag in Box
Specification
55.00 x 22.00 mm
Trademark
KLT
Origin
China
Production Capacity
500000 Pieces
Product Description
5MP OV5640-1B MIPI and DVP Parallel Interface M12 Fixed Focus Camera ModuleCamera Module No. KLT-X9MF-OV5640-1B V1.2
| Camera Module No. | KLT-X9MF-OV5640-1B V1.2 |
| Resolution | 5MP |
| Image Sensor | OV5640-1B |
| Sensor Type | 1/4" |
| Pixel Size | 1.4 um x 1.4 um |
| EFL | 0.90 mm |
| F.NO | 2.00 |
| Pixel | 2592 x 1944 |
| View Angle | 220.0°(DFOV) 187.0°(HFOV) 144.0°(VFOV) |
| Lens Dimensions | 13.00 x 13.00 x 13.56 mm |
| Module Size | 55.00 x 22.00 mm |
| Module Type | Fixed Focus |
| Interface | MIPI and DVP Parallel |
| Auto Focus VCM Driver IC | Embedded |
| Lens Model | KLT-LENS-TRC-F5022A6-02 |
| Lens Type | 650nm IR Cut |
| Operating Temperature | -30°C to +70°C |
| Mating Connector | FX12B-40P-0.4SV |
