X-ray Luggage Metal Detector Small Tunnel Size Use for Hotel/Airport
Basic Info.
Model NO.
VX-5030A
Form
Conveyor Belt
Application
Security Check
Type
Baggage Scanning
Certification
CE, ISO
Customized
Customized
Alarm Form
Audible Alarm
Usage
Auto, Door, Security Inspection
Inspection Tunnel Size
500*300mm Size
Load Ability
Customized
Penetration
8mm Steel
Film Safety
ISO1600
Generate Angle
60 Degree
Install
No Need
Transport Package
Strong Ploywooden Case Packaging
Specification
CE and ISO
Trademark
Vfinder/shanan
Origin
Guangdong Dongguan
HS Code
9031499090
Production Capacity
100 Sets Per Week
Product Description
General Specificationx-ray luggage scanner
x-ray baggage scanner
Airport x ray scanner
security x ray machine
x-ray screening machine
luggage scanner
baggage scanner
x-ray security scanner
airport x-ray scanner
baggage scanning system
airport baggage scanner
luggage x-ray machine
airport x ray machines
* Tunnel Size: 500(W)*300(H)mm
* Conveyor Speed: 0.22m/s
* Conveyor Max Load: 150kg
* Wire Resolution: 38AWG
* Penetration: 8mm Steel
* Film Safety: Guarantee ISO1600 Film
* X-ray Leakage: <0.2 μ Gy/h (at a distance of 5cm From external housing)
X-ray Generator
* Generate direct: Upward
* Generate angle: 60 degree
* Anode Voltage: 80Kv
* Anode power: 0.6mA
Cooling / Duty Cycle: Oil Cooling /100%
Image System
* X-ray Sensor: L-Shaped Photodiode Array (monoenergetic), 12bit Deep
* Monitor: High Resolution Color, LCD Accord, 17 inch
* Image Processing: Edge enhancement, image strengthening, image lightening, , reducing darkening,
Image returning, image retrieval.
* Image Grey Level: 4096
* Image Max Resolution: 1024 * 1280 pixel
* Image Processing: 24bit for processing real time
* Image storage: Storage 60000 pictures in real time
* Zoom: 32 Times Enlarge, Whole screen continuous observation
Installation Data
Operation temperature/Humidity: 0-45º C/20%-95%(non-condensing)
Storage Temperature/Humidity: -20º C-60º C/20%-95%(non-condensing)
Operation Power: 220VAC(± 10%)50± 3Hz
Power Consumption: 0.8KVA
Noise: <65dB
Tunnel Size: | 500(W)*300(H)mm |
Conveyor Speed: | 0.22m/s |
Conveyor Max Load: | 100kgs |
Dose per Inspection: | <2.9 μGy/h |
Resolution: | <0.101mm Metal Wire |
Penetration: | 8mm Steel |
Film Safety: | Guarantee ISO1600 Film |
X-ray Leakage: | <0.05 μGy/h (at a distance of 5cm From external housing) |
Generate direct: | Upward |
Generate angle: | 60 degree |
Anode Voltage: | 70Kv |
Anode power: | 0.4 to 0.5mA |
Cooling / Duty Cycle: | Oil Cooling /100% |
X-ray Sensor: | L-Shaped Photodiode Array (mono-energetic), 12bit Deep |
Monitor: | High Resolution Color, LCD Accord, 17 inch |
Image Processing: | Edge enhancement, image strengthening, image lightening, reducing darkening, image returning, image retrieval. |
Image Grey Level: | 4096 |
Image Max Resolution: | 1024 * 1280 pixel |
Image Processing: | 24bit for processing real time |
Image storage: | Storage 60000 pictures in real time |
Zones & Zoom: | 1-9 Image regions, 2, 4, 8, 16 Times Enlarge, Whole screen continuous observation |
Operation temperature/Humidity: | 0ºC-45ºC/20%-95%(non-condensing) |
Storage Temperature/Humidity: | -20ºC-60ºC/20%-95%(non-condensing) |
Operation Power: | 220VAC(±10%)50±3Hz |
Power Consumption: | 1.0 KW (max), 0.3KW(working) |
Noise: | <65db |
