Dongfeng 190HP Garbage Compactor Truck 14000L Refuse Compactor Truck

Product Description

DONGFENG 190HP Garbage Compactor Truck 14000L Refuse Compactor Truck
Garbage Compactor Truck, also called Compressed Garbage Truck, Compactor Garbage Truck, Compressed Garbage Truck, Rear Loader Garbage Compactor Truck, Waste Compactor Truck, Waste Compressed Truck, Refuse Compactor, Trash Compactor Truck, Trash Truck
How the Garbage Compactor Truck Works?
The garbage compactor trucks are loaded by sanitation engineers along neighborhood streets. The trash is loaded into a hopper in the back of the truck of rear loaders. Hydraulic cylinders operate the compacting mechanism, which takes the trash out of the hopper and places it into the body of the truck.
How much does a Garbage Truck hold?
Different types of garbage trucks that hold different amounts of waste. The truck that comes through your neighborhood can hold anywhere from 5 tons to 22 tons of waste.
The available chassis brands for Garbage Compactor Truck are SINOTRUK, DONGFENG, FAW, FOTON, JAC, JMC, HYUNDAI, etc.

Garbage Truck Specification
General	Model	CLW5140BBLJCDF14
	Chassis Brand	DONGFENG
	Overall Dimension	Appro. 8500*2500*3400 (mm)
	GVW	Appro. 18000 (kg)
	Truck Tare Weight (kg)	Appro. 9900 (kg)
	Garbage Container Capacity	Appro. 14CBM
	Drive Type	4x2, Right Hand Drive with power assisted steering
	Drive Speed	≥90Km/h
Cab	Type	One and a half row cab, forward control type, all welded steel cab of tilt type, mechanical cab tilting, rear mechanical cab suspension, adjustable driver seat
	No of Seats	3 persons allowed, including driver, with safety belts
	Number of Doors	2
	Air Conditional	With air conditional
	Electric System	24V
	Audio System	FM/AM radio, CD/USB player
Engine	Brand	DONGFENG CUMMINS
	Model	EQB180 20
	Fuel Type	Diesel Fuel
	Emission Standard	Europe II
	Type	Water-cooled four-stroke, direct injection, turbocharged & intercooled
	Nos of Cylinder	6
	Cylinders Arrangement	In-line
	Max Output Power	132 (kw)
	Exhaust	5900(ml)
	Max output power/rated speed	180/2500 (hp/rpm )
	Max torque/rotate speed	610/1500 (N.m/rpm)
Fuel System	Fuel Tank Capacity	160Ltr
	Material	Steel fuel tank
Gear Box	Model	DF6S900
	Type	Manual
	Forward Speeds	6
	Reverse Speed	1
	Synchronizer	Yes
	Forward Ratios	6.938;3.996;2.320;1.493;1.0;0.814
	Reverse Ratio	6.188
Clutch	Plate's Diameter	¢395mm
	Operation System	Hydraulic control with air booster, pushing
Bridge	NOs of Axle	2
	Front Alex	Elliot type, I beam section
	Front axle load-bearing (kg)	4500
	Rear Alex	Single reduction
	Rear axle load-bearing (kg)	9000
Suspension	Front	7- Leaf spring with shock absorber
	Rear	(9+6)-leaf spring
Electric System	Voltage	24V
	Battery Capacity (A.h)	100X2
Braking System	Full air brake system, split pneumatic circuit , parking spring brake acting on rear axles, exhaust brake
Tire	Type	10.00R22.5
	Nos	Total 7 pieces, including one spare tire

Garbage Compactor Truck Upper-Body Specification
Garbage Container	Volume	14CBM
	Material	Q345
	Thickness (side/bottom)	5mm/5mm
Hydraulic Pump	1 set
Multi-way Valve	1 set
Flap Cylinder	2 set
Lifting Cylinder	2 set
Scraper Cylinder	2 set
Skateboard Cylinder	2 set
Push plate Cylinder	1 set
The Electromagnetic Valve	2 set
Dirty Tank Volume	200L
Filing Time	8-10s
Filling Cycle Time	20-28s each time
Discharge Type	Flat-pushing and Dumping
Dumping Time	15-20s
Hydraulic Pressure	16Mpa
Controlling Way	Manually and Electrical control

AFTER-SALE SERVICE
Warrant special vehicles and equipment we supplied are manufactured with mature technology, nice workshop, under strict quality control . They are free from defects in workmanship and material . With correct use and normal maintenance , you will enjoy a happy service on your vehicles or equipment as below :
★ Function Life
The vehicles are expected to be functioning 10 (ten) years with availability of spare parts.

★ Warranty
The customers can enjoy a maximum warranty period of 12 months or 10000 kilometers, whichever comes first, from shipment date on Bill of Lading.
During this period, if any failure, we will send replacement parts and components to customers by DHL, UPS, FEDEX free. Normal wear or fast consumables are excluded.

After this period, the parts can be provided at cost price.

This warranty does not cover damage due to improper use, accident or misuse or damage due to any unauthorized services.

If the goods are determined to be defective in materials or workmanship, we will, at ours option, repair or replace the goods.

★ Technical Support
For our supplied products, you can forever enjoy technical support whatever by phone call or email. We will respond aggressively to provide a prompt solution.

★ Onsite Training
On-site training could be executed if this term is included in the contracts agreed.

★ Onsite Service
We can assign our engineers to go to destination for on-site service if this term is included in the contracts agreed. Even service workshop could be built if the order comes to certain quantity.
