Customized 2.4G ~5.8g WiFi Built-in PCB Antenna Internal GPS Antenna with SMA Plug Connector

Product Description

Custom Made GPS, GSM, BT/WiFi, DVB-T TV, Laptop, CDMA, 2.4G, 5G Coaxial Cable Antenna2G: CDMA450, GSM850/900/1800/1900MHz, CDMA800/1900MHz3G: WCDMA4G: FDD-LTE, TD-LTE, 450MHz, 3400-3800MHzWiFi: 2.4GHz, 5.8GHzBluetooth: 2.4GHzRFID/UHF/NFC: 13.56MHz, 433MHz, 750MHz, 915MHzGPS/BDS/GLONASS/GALILEO: 1559MHz-1615MHzAn antenna is an array of conductors (elements) electrically connected to the receiver or transmitter. Antennas can transmit and receive radio waves in all horizontal directions equally (omnidirectional antennas) or in a particular direction (directional or high-gain antennas). These antennas may include parabolic reflectors, horns, or parasitic elements, which direct the radio waves into a beam or desired pattern. Achieving strong directivity and good efficiency is challenging with antennas smaller than a half wavelength. Uses of GPS, GSM, BT/WiFi, DVB-T TV, Laptop, CDMA, 2.4G, 5G Coaxial Cable Antenna

Electrical performance
Frequency range	1700-1800MHZ
Voltage standing wave ratio	≤1.5
Input resistance	50Ω
Gain	(3.5±0.5)dBi
Polarization Type	vertical
Horizontal beam width	(65±5)°
Vertical beam width	(50±2)°
Front-to-rear ratio	≥3dB
Maximum input power	50W
Connection type	antipole SMA
Third-order intermodulation	≤-107dBm
Protect Raiden	Direct Current
Mechanical
Size	L=50mm
Weight	0.1kg
Cover material	ABS+PU
Working temperature	(-40~+60)°

Used on the roof of a car with a magnetic antenna sucker

Connector	SMA/FME/TNC/BNC/N/SMB
Plating	Gold Plated / Nickel Plated / Black Chromium Plated
Radome material	ABS
Temperature range	-40~+85°C
Vibration	100m/s2 (10~500Hz)
Impedance	50 OHM
Frequency Range	433M/GSM/2G /3G/GPRS/4G/ISM/5.8G
Peak gain	0~12dBi
Radiation pattern	Omin-directional in azimuth
Contact resistance	≤0.4 OHM @ inner contact ≤1.5 OHM @ outer contact
Max power	50W
VSWR	≤ 1.2
