450/750V H07rnf H07rn-F 5 Core 25mm 5X25mm2 5g25 Epr EPDM CPE Insulated Electric Flexible Rubber Power Cable

Product Description

Product Parameters

Rubber Insulated Mining 8kv Power Cable-ICEA S 75-381(SHD-GC)
Number of Cores and conductor size	Conductorstrand	Nominal Thickness of Insulation	Ground conductor size	Ground -check conductor size	Nominal Thickness of jacket	Approx. Overall Diameter	Approx. mass	Ampacity
AWG/kcmil	No	mm	AWG	AWG	mm	mm	kg/km	A
3×4	259	3.8	8	8	5.2	49.3	3594	122
3×2	259	3.8	6	8	5.6	53.8	4554	159
3×1	259	3.8	5	8	5.6	56.1	5104	184
3×1/0	259	3.8	4	8	5.6	58.9	5700	211
3×2/0	329	3.8	3	8	6.0	62.5	6593	243
3×3/0	413	3.8	2	8	6.4	66.5	7738	279
3×4/0	532	3.8	1	8	6.4	69.8	8713	321
3×250	608	3.8	1/0	6	6.4	73.4	9948	355
3×300	741	3.8	1/0	6	6.7	77.2	11384	398
3×350	851	3.8	2/0	6	7.1	81.3	12739	435
3×500	1221	3.8	4/0	6	7.5	90.4	16757	536

Detailed Photos
Packaging & Shipping
* We can design and produce ACSR according to client's requirement. Any requirement, feel free to contact us!
Company Profile
Established in 1994,Henway Electric Group Inc has now developed into an innovative enterprise with strong R&D ability after 20 years in the
industry. It covers an area of 210,000 square meters and has more than 2,000 employees. It has successively introduced about 2,000 items of advanced R&D, production and testing equipment. The annual production capacity exceeds 30 billion yuan.
Henway's products can be divided into four categories,namely power cable, wire &cable for electrical equipment, communication cable and
building wire.They include insulated power cable of 220KV and below, Rubber insulated cable of 35KV and below, Aerial insulated cable,overhead
conductor,Mining cable etc,a total of nearly 30 product series with nearly 4,000 types and 50,000 items.The products are widely used in the fields of infrastructure, utility, hydro-water projects, iron, mining, petroleum, chemical industry,building,subway, high-speed rail,airports,etc.
They have been exported to more than 100 countries around the world.
Henway passed ISO 9001,ISO 14001,OHSAS 18001,and successively acquired TUV certificate,CE certificate,UL certificate and so on.More than 30 years of development and cultivation makes the extraordinary achievements of Henway.Henway is still promoting the enterprise's scale,technology
and brand construction.
Heway Cable-make pioneering efforts and forge ahead !
Certifications
FAQ 1. Q:How does your factory control the quality?
A:Factory has a quick and enthusiastic merchandisers team, strict and responsible QC team, service for many well-known brands all around the world with our high-quality products and strict.
2. Q:Can I visit your company?
A: Sure,If you need,we will arrange the driver to pick you up.
3. Q:How can I get some samples?
A: Contact me on below,Determin sample and address for shipping.
4. Q:Have you ever supplied cables to our country?
A: Henway Cables have been sold to over 100 countries and regions in the world. you can contact me for details.
5. Q:What is your MOQ?
A: MOQ Normally 500 meters for big diameter cables. Please contact me for detail info if you have specific cable requirement.
6. Q:When can I get the price?
A: Usually quote within 6 hours after we get your inquiry.
7. Q:How long is your delivery time?
A: According to your order's quantity. Usually our lead time is 3 - 20 working days.
For more information about wires and cables, please feel free to contact us. Your inquiries will be replied to within 6 hours!!
