ERW Tube Mill High Frequency Straight Seam ERW Hf Welded Tube Mill

Product Description

High Frequency Welded Tube MillERW pipe mills is a characterized product of HUAYE that are developed through years of research to combine the advanced knowledge and technology of the market.
The main product includes high-level steel casing and tubing pipe mill, structure pipe mill, fluid transfer pipe mill, and small dia. thick wall pipe mill.
HUAYE has an experienced team with strong technical skill and knowledge. Through years of hard work, HUAYE's ERW pipe mill has occupied the market of more than 20 provinces of China and was exported to Korea, Mexico, Thailand, Uzbekistan, Kazakhstan etc. HUAYE ERW pipe mill were highly received by customers from China and over the world.
Equipment list

No.	Name of equipment	Quantity	Note
1	Double Uncoiler	1	Load and feed strip coil
2	shear and welder	1	Shear and weld joint strip end
3	Cage accumulator	1	Accumulate strip to ensure continuous production during coil change
4	Forming machine	1	Form and weld the strip to tube shape
5	Cooling trough	1	Cooling the hot tube body after welding
6	Sizing machine	1	To force the welded tube to exact size and shape
7	Computer controlled flying saw	1	Friction saw, Cut the tube to length
8	Rail type run out table	1	Deliver produced tubes out of the machine
9	Packing tube rack	1	Manual packing
10	Solid HF welding machine	1	200KW; China brand
11	Hydraulic system	-	Chinese famous brand
12	Roll tooling	-	Separately ordered

Process flow:
Loading → uncoiler → End shear → Accumulator → Leveling → Forming → HF welding → Cooling → Sizing → Straightening → Flying saw → Run out
