High Quality Dooxin 53ton/5ton/7ton Dx550PC-9 Excavator Pelle De Haute Qualité

Product Description

Product Name
High Quality DooXin 53ton/5ton/7ton DX550PC-9 Excavator with ISO900
Product Parameters

Performance parameters
Weight	53T
Bucket capacity	2.7m3
Engine rated power	300kw
Swing speed	10.3min -1
Travel speed (high/low)	5.6/3.3km/h
Ground specific pressure	0.9kg/cm2
Gradeability (%)	70
Digging force	279KN
Boom length	6300mm
Arm length	2900mm

Working range
Maximum digging depth	7795mm
Maximum digging height	10787mm
Maximum unloading height	7915mm
Maximum digging radius	11800mm
Minimum turning radiusc	5210mm

Dimensions
Transport length	12230mm
Transport arm height	3705mm
Tumblers distance	4475mm
Radius of gyration platform end	3800mm
Counter weight ground clearance	1460mm
Track gauge	3303/2743mm
Total width of undercarriage	3900mm
Width of upper structure	3400mm
Width of track shoe	600mm
Ground clearance	770mm
Total length of travel mechanism	5455mm
Total width of cabin	1010mm
Overall height	845mm

Detailed Photos
About Us
About Fortius
Fortius, located in the capital city of Shandong Province Jinan ,the transportation center of high speed rail and air line,which makes the communication with the world much easier.
The company has Purchase Department,Quality Control Department,Ware House Department ,Domestic sales and Foreign Trade Departments ,as well as the Marketing Department with the countries development and improvement it will expand both in scale and functions.
The company is a comprehensive company both in domestic and abroad markets,its main advantages is it has long term cooperation strategy with the leading trucks and spare parts manufacturers of SINOTRUK,CAMC, SHACMAN,BEIBEN etc,with the low manufactured cost,the guaranteed high quality products as well as most professional staff,it will become the more and more popular by clients.
Obey the faith and rules of"Quality First,Service Best"the company will be know and popular by more and more users and clients worldwide.
Advantage
1. Exclusive highly efficient hydraulic control system2. Powerful travel traction3. Effectively prevent mixing of soil and rock4. Highly efficient and rapid operations5. High-strength frame structure and greater ground clearance6. Safe and open engine hood7. Convenient and swift maintenance
Working range diagram
Dimensions diagram
Our Workshop
Visiting & Exhibition
Packaging & Shipping




FAQ

Q1.What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay
the balance.
Q2.What's your minimum quality?
1 unit
Q3.How about your delivery time?
A: Generally, it will take about 20 to 30 days after receiving your advance payment. The specific delivery time depends on
the items and the quantity of your order.
Q4.What's the warranty?
A: Engine, transmission, axle guarantee one year (Any faulty caused by incorrect operation or man-made factors is
exclusive of guarantee.)
Q5.What's your after-sale service?
A: We provide technical support for our trucks and whole life parts supply
