150 Psi PE Liner Fiberglass FRP Vessel Tank 1035 with Ce Certificate

Product Description

Product Description 150 Psi PE Liner Fiberglass FRP vessel Tank 1035 with CE Certificate
Characteristics of FRP tank:
>> Opening temperature: 1-49°C
>>Operating pressure: 150PSI
>>Color : Natural/ bule/ grey/ black
>> Bursting pressure: 232PSI
>> Fatigue test: 100.000times incessantly cycle test
>> Different inner container:PE/ FRP
>>Opening diameter: 2.5''thread, 4" thread and 6'' flange
>> Certificates: CE; ISO9001 etc.
>> Warranty: 1 years
Description about our FRP tank
1)Adopt high-performance resin and glass fiber winding, Liner uses PE plastic, FRP high quality material to blow molding manufactory, using importing micro-computer controlling equipment to shape, anticorrosion, high or low resistance, high tenacity, satisfy customers' different application well.
2) Merits: pretty twisting pattern, sophisticated manufacture, long lifetime, etc.
3) Dimension: 7''-63" PE liner, 72″ adopt FRP liner
4) Opening: 2.5"whorl, 4"whorl mouth, 6″flange
Application of FRP tank: All feed water and waste water treatment application, included multi-media filter and softener.

NO.	specification		volume	top opening	bottom opening	LA	LB	LC	×	D
	Inch	mm	L			mm	mm	mm	mm	mm
1	7×13	φ180×335	6.3	2.5"NPSM	\	334	320	304	198	181
2	7×17	φ180×430	8.6	2.5"NPSM	\	428	414	398	292	181
3	7×35	φ180×905	20.1	2.5"NPSM	\	904	890	874	768	181
4	8×17	φ205×445	11.3	2.5"NPSM	\	446	432	416	292	206
5	8×35	φ205×905	24.0	2.5"NPSM	\	905	891	875	751	206
6	8×44	φ205×1130	32.5	2.5"NPSM	\	1131	1117	1101	977	206
7	9×35	φ230×905	32.0	2.5"NPSM	\	905	891	875	734	232
8	9×42	φ230×1085	39.0	2.5"NPSM	\	1085	1071	1055	914	232
9	9×48	φ230×1230	44.7	2.5"NPSM	\	1232	1218	1202	1061	232
10	10×17	φ255×445	17.8	2.5"NPSM	\	447	433	417	259	257
11	10×35	φ255×905	38.6	2.5"NPSM	\	903	889	873	715	257
12	10×44	φ255×1130	49.5	2.5"NPSM	\	1130	1116	1100	942	257
13	10×54	φ255×1390	61.9	2.5"NPSM	\	1390	1376	1360	1202	257
14	12×52	φ300×1340	84.8	2.5"NPSM	\	1342	1332	1312	1115	305
15	12×65	φ300×1650	106.3	2.5"NPSM	\	1650	1640	1620	1425	305
16	13×54	φ330×1400	103.6	2.5"NPSM	\	1400	1390	1370	1155	334
17	14×65	φ355×1670	145.6	2.5"NPSM	\	1671	1661	1641	1410	360
18	14×65	φ355×1670	145.6	4"-8UN	\	1670	1661	1641	1410	360
19	16×65	φ400×1670	187.7	2.5"NPSM	\	1672	1662	1642	1380	410
20	16×65	φ400×1670	187.7	4"-8UN	\	1671	1662	1642	1380	410
21	16×65	φ400×1670	187.7	4"-8UN	4"-8UN	1671	1662	1642	1380	410
22	18×65	φ450×1670	237.0	4"-8UN	\	1670	1640	1612	1310	465
23	18×65	φ450×1670	237.0	4"-8UN	\	1670	1640	1612	1310	465
24	21×69	φ530×1750	316	4"-8UN	\	1750	1563	1685	1195	540
25	21×69	φ530×1750	316	4"-8UN	4"-8UN	1750	1563	1545	1195	540
26	24×72	φ600×1850	441	4"-8UN	\	1850	1750	1715	1330	612
27	24×72	φ600×1850	421	4"-8UN	4"-8UN	1850	1680	1645	1260	612
28	24×87	φ600×2200	520	4"-8UN	4"-8UN	2200	2030	1995	1610	612
29	30×72	φ750×1850	676	4"-8UN	\	1850	1750	1715	1240	765
30	30×72	φ750×1850	640	4"-8UN	4"-8UN	1850	1670	1635	1160	765
31	30×87	φ750×2200	790	4"-8UN	4"-8UN	2200	2010	1975	1500	765
32	36×72	φ900×1850	857	4"-8UN	4"-8UN	1850	1600	1554	1000	918
33	36×94	φ900×2400	1093	6"flange	6"flange	2400	2150	2044	1370	918
34	40×72	φ1000×1850	1046	4"-8UN	4"-8UN	1850	1605	1559	945	1020
35	40×94	φ1000×2400	1478	6"flange	6"flange	2400	2155	2109	1495	1020
36	48×72	φ1200×1850	1202	6"flange	6"flange	1850	1558	1451	595	1224
35	48×94	φ1200×2400	1824	6"flange	6"flange	2400	2108	2001	1145	1224
36	60×83	φ1500×2100	2158	6"flange	6"flange	2100	1780	1670	630	1530
37	60×94	φ1500×2400	2688	6"flange	6"flange	2400	2080	1970	930	1530
38	63×83	φ1600×2100	2580	6"flange	6"flange	2100	1780	1670	630	1620
39	63×94	φ1600×2400	3150	6"flange	6"flange	2400	1788	1970	1620	1620
40	72×94	φ1800×2400	3561	6"flange	6"flange	2400	2088	1908	1620	1836
