Vertical horizontal universal tool milling machine X8140
| US$15,000.00-18,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
X8140
Structure
Lifts
Milling Cutter Type
Vertical Milling Cutter
Milling Cutter Structure
Indexable Type
Controlling Mode
Artificial
Automatic Grade
Manual
Precision
High Precision
Certification
CE, RoHS, ISO 9001
Condition
New
Vertical Table Size
250X1060mm
T Slot No./Width/Distance
6/16/63mm
Spindle Taper
ISO40
Motor
5kw
Speed
2400rpm
Transport Package
Plywood Case
Specification
1400kgs
Trademark
HOTON
Origin
Shandong, China
HS Code
8459590000
Production Capacity
5PCS/Month
Product Description
UNIVERSAL TOOL MILLING MACHINE X8140
X8140 universal tool milling machine is a versatile machine,extensively used for metal cutting
manufacturer in different mechanical industries.
It is particularly suitable for half-finished and precision-machined manufacturing of machine parts,
which has complicated shapes.
It has a great advantage for manufacturing middle and small parts to use this machine tool.
SPECIFICATIONS:
| MODEL | X8140 | |
| Horizontal working surface | 400x800mm | |
| T slot no./width/distance | 6 /14mm /63mm | |
| Vertical working surface | 250x1060mm | |
| T slot no./width/distance | 3/14mm /63mm | |
| Max. longitudinal (X) travel of working table | 500mm | |
| Max.cross travel (Y) of horizontal spindle slide | 400mm | |
| Max. vertical travel (Z) of working table | 400mm | |
| Distance from axis of horizontal spindle to surface of horizontal working table | Min. | 95±63mm |
| Max. | 475±63mm | |
| Distance from nose of horizontal spindle to surface of horizontal working table | Min. | 55±63mm |
| Max. | 445±63mm | |
| Distance from axis of vertical spindle to bed guideway (Max.) | 540mm | |
| Range of spindle speeds (18steps) | 40-2000r/min | |
| spindle taper bore | ISO40 7:24 | |
| Range of longitudinal(X),cross(Y) and vertical (Z) traverse | 10-380mm/min | |
| Rapid feed of longitudinal(X),cross(Y) and vertical (Z) traverse | 1200mm/min | |
| Travel of vertical spindle quill | 80mm | |
| Main drive motor power | 3kw | |
| Total power of motor | 5kw | |
| Overall dimension | 1390x1430x1820mm | |
| Net weight | 1400kgs | |
