Dustless Blasting Machine for Sale dB150 dB225 dB500 dB800 dB1500 dB3000

Product Description

Dustless blasting machine 1. Technical parameters

Model Item	DB150	DB225	DB500	DB800	DB1500	DB3000
Blasting mode	Air jet	Air jet	Air jet	Air jet	Air jet	Air jet
capacity	0.03m³	0.06 m³	0.14 m³	0.23 m³	0.42 m³	0.85 m³
Compressor	60+CFM	185+CFM	185+CFM	300+CFM	425+CFM	425+CFM
Blast time	~15min	~30min	~60min	~90min	~2+hours	~4+hours
Size (L/B/H)(mm)	1067/584/533	1397/660/863	1397/914/1016	1626/914/1016	1981/1245/1245	2490/1245/1245
Weight (Kg)	72	120	167	194	380	544
Operating pressure (PSI)	30-150	30-150	30-150 I	30-150	30-150	30-150
Operating tube length (m)	15	15	15	15	15	15
Blasting nozzle diameter(mm)	∅10	∅10	∅10	∅10	∅10	∅10

Requirement of air compressor
4-10 bar, 185-375 CFM, 30-150 PSI, 0.2-1.0 Mpa
Air consumption: 5.2m³/min
Includes
A. 10m blast hose(diameter is 32mm)
B. Deadman activator valve
C. Boron carbide nozzle(diameter is 10mm)
D. Fill funnel
E. Lifetime warranty on blast pot
2. Consumables
3. Commercial terms
1. This is FOB price, it don't include freight and air compressor price, customer need to prepare it based on air consumption of each model.
2. Production time is 20 days after receiving the payment.
3. Payment terms: payment term is 100% in advance by TT.
4. Packaging: Plywood box
5. Warranty: one year from delivery time.
6. Delivery port: Qingdao port, China
4. Product Application
Our dustless blasting machines are mainly designed and integrated with the wide range of nozzles, wet blast attachments, internal pipe cleaning devices, dust free blasting heads, abrasive control device.

Dustless blasting recognizes the needs of the industry and our machines offer all the features that the professional use requires. All machines can be fitted with a well designed and proven single piece remote control dead man switch and silencer which significantly reduce labour cost, improve efficiency of abrasive, performance and safety.

The machines are constructed for a maximum 150 PSI working pressure. The pneumatic abrasive remote control valve can achieve operators to stop or start .

5. Working Principle
Wet sanddustless sand blastingting machine, also known dustless sand blasting water sand machine, liquid sandbldustless sand blastingting machine, wet sandbldustless sand blastingting machine. Wet sandbldustless sand blastingting machine and dry sandbldustless sand blastingting machine is different place, is the wet sandbldustless sand blastingting machine is sand and abrdustless sand blastingive placed in the water, so that water sand mixed together, the use of grinding fluid pump and compressor high-pressure gdustless sand blasting, through the gun nozzle Rapid spray to the object to be processed, so dustless sand blasting to achieve the effect of cleaning the surface of the object.
6. Main Feature
1. High quality surface appearance
2.High productivity efficiency
3.Low cost
4. Environmental friendly
5. Lower abrasive consumption
6.Safe, no sparking
7.Less contamination
8.Not necessary to stop nearby jobs.
9.Removes scale for a paint ready surface.
10. Requires only a parking space
11. Does not warp metal
12. Leaves a primer-ready surface
13. Easy to clean up
14. Prevents rust for 72 hours
