Fabric Waste Cutting Machine for Recycling for Jeans/Clothes/Waste Fiber/Cotton Textiles

Product Description

Features
1. Uses the cutting between the blade roller and fixed blade to cut yarn, fabric etc. into small pieces.
2. Length is adjustable from 5 cm-20 cm .Speed can be adjustable according to customers' special requirement.
3. It can meet the requirement of best quality, high output, low cost and also has a feature of reasonable structure, easy operation and the safe production and so on.
TECHINICAL DESCRIPTION OF EQUIPMENTS

NO.	ITEM	DESCRIPTION
1	Model	GM800C
2	Dimension of M/C	3200L1000W1100H(mm)
3	Weight	800kg
4	Total power	5.5+1.5kw
5	Main motor	3 phase AC power 50Hz
6	Protection	Main motor overload protection Open phase protection
7	Working width	350mm/ Unadjustable
8	Number of Rotating blade	4
9	Number of Fixed blade	2
10	Bearing	High quality bearings
11	The connection method	Conveyor belt
12	Electrical components	Zhengtai
13	Capacity	800KG/H
14	Note	CNC cutting equipment and machining center equipment will be used in the manufacture of the machine. All rotating shaft through dynamic balance test.

Product Features:
1.The cutter adopts Cr12mov super hard alloy material, the vacuum quenching treatment, reaching 62 degrees above, adjustable use;
2.The main shaft of the tool holder adopts 40Cr shaft special material, high torque and strong toughness;
3.Widen the conveyor belt,1400mm long and 350mm wide;
4.Electrical control cabinet can operate in one hand,reversible switch;
5.Overload protector, the cutting range is 3-75mm.
Our Sercive:
1.We have After-sale department,every client can get a timely feedback when they have any trouble about our machine.
2.We have installation team,if you need,we will provide installation service.
3.Our equipment warranty period is 1 years,within this time,we will provide free maintenance.
4.If you have any other question or demand,please feel free to contact our businessmen,they will reply you within 8 hours.
