YAMAHA Outboards Motor More Cheaper Price

US$1,200.00-1,300.00 5 Pieces (MOQ)

Basic Info.

Model NO.

Yamaha Outboards Prices (Motores)

Engine Capacity

1-2L

Engine

2 Stroke

Engine Position

Outboard

Condition

New

Stroke

Two Stroke

Weight

75kg

Displacement

703cc

Full Throttle Operating Range

4500-5500 R/M

Gear Position

Forward-Neutral-Reverse

Gear Ratio

2.08 (27:13)

Fuel Tank Capacity

24L

Transport Package

Carton

Specification

CE,

Trademark

EARROW

Origin

Jinhua China

HS Code

8407210000

Production Capacity

30000piece/Year

Product Description

Product: Yamaha Outboards Prices (Motores)
All 2stroke series are simialr with yamaha base, spare parts exchangable with Yamaha parts.
9.9hp /15hp are develop basis on 15HP ENDURO series of Yamaha, very compete and powerful.
Series:
Two stroke: 2.5hp; 3hp; 3.5HP,5hp; 6hp; 9.9hp; 15hp; 18hp; 30hp,40HP;
Four stroke: 2.5hp; 4hp; 5hp; 6hp,9.9hp,15hp
30HP Tested by Sweden/South American customer successfully
Certification
CE/SGS/ISO 9001
High quality imported parts from Japan and Taiwan to assure longer engine life
Earrow outboards Quality control system:
Type: Outboard Engine 30hp 2stroke
Our strength
1. Lower noise
The lowest noise among same two stroke / four stroke HP engines
2. More Stable
Most plastic parts and die casting parts are made by ourselves, USE high quality imported parts from Japan & Taiwan
3. Top cover more durable
no broken even hit by Steel Bar.
Color of One-step moulding technology instead of painting
4. Oil Painting / spare parts surface treatment Johnson Standard---PPG painting
5. All engines with SGS/ CE certification of Machinery Directive 2006/42/EC, EMC Directive 2004/108/EC Annex II.

Model

T2.5A

T3A

T4c

T5c

TE9.9D

TE15D

TE18D

25H

30H

Dimension

Overall length

628mm (24.7 in)

677mm(26.7in)

878mm (34.6 in)

843mm (33.2 in)

Overall width

289 mm (11.4 in)

322mm(12.7in)

363 mm (14.3in)

399mm (15.7in)

Overall height S

997 mm (39.3 in)

978mm(38.5in)

1062mm (41.8in)

1146mm (45.1in)

Overall height L

1124 mm (44.3 in)

1011mm(39.8in)

1189 mm (46.8in)

1273 mm (50.1in)

Net weight (S/L)

16.5kg/ 17kg

20.5kg/ 21kg

38kg/ 40kg

53kg/ 54.5kg

Gross weight (S/L)

21kg/ 21.5kg

27kg/ 27.5kg

58kg/ 60kg

63kg/ 64.5kg

Package Size (S/L)

111*51*35 cm³ / 124*51*35 cm³

109*60*38 cm³ / 122*60*38 cm³

121*71*44 cm³

121*72*47 cm³

Full Throttle Operating Range

4500-5500 r/m

Maximum Output

1.8kw/2.5hp

2.2kw/3hp

2.9kw/4hp

3.7kw/5hp

7.3kw/9.9hp

11kw/15hp

13.2kw/18hp

18kw/25hp

22.1kw/30hp

Idling Speed

1200±50r/m

1150±50r/m

1050±50r/m

1100±50r/m

Type

Two Stroke

Displacement

70.0cc

103.0cc

246cc

496.0cc

Bore×Stroke

46.0×42.0mm(1.81×1.65 in)

54.0*45.0 mm

56.0×50.0mm

72.0×61.0mm(1.81*1.65in)

Ignition System

CDI

Spark Plug

NGK BR7HS-10

NGK B8HS-10

Spark Plug Gap

0.9-1.0mm

0.6-0.7mm

0.9-1.0mm

Control System

Tiller Handle

Starting System

Manual

Starting Carburation System

Choke Valve

Gear Position

Forward-Neutral

Forward-Neutral-Reverse

Gear Ratio

2.08 (27:13)

Trim and Tilt System

Manual Tilt

Recommended Fuel

Unleaded Gasoline

Recommended Engine Oil

2-stoke outboard motor oil

Fuel Oil Ratio

50:1

Gear Oil

0.075 L

0.100L

0.250L

0.320L

Fuel Tank Capacity

1.4 L

2.8 L

24 L

12 L

For more information,you can check our viedos on Youtube:

https://youtu.be/6zVUdviJ49g

http://youtu.be/yW9w4O6YQwU

https://youtu.be/6zVUdviJ49g

http://youtu.be/LFld0t_kIhc

http://youtu.be/a322K0u8asw

https://youtu.be/kQjuH3cXPwk
